Mitutoyo DP-1VR User Manual

- 29 -
OPERATION
Function Operation Print
● Power ON
● Time print
● Data cancel
Prior input is canceled.
● Data input
All input data is cleared.
● Data input
Limit judgment is conducted for
the input data, displayed (LED)
and printed.
POWER
PRINTER ON/OFF +
DATA
CE
CL
DATA
DATA
DATA
* DP-1VR *
* MODE 1*
DATE 2000/ 2/ 2
TIME 13: 35
*LIMIT DATA 1*
LSL 12.36 mm
USL 25.67 mm
TOL 13.31 mm
DATE 2000/ 2/ 2
TIME 13: 35
* CANCEL *
* CLEAR *
H 1 12.00 mm
2 26.25 mm
G 3 32.56 mm
Input data, and relationship of display (LED) and print.
3.4 Data input, cancel, clear
Table 2 DP1 mode1, operation example 2
Input
Print
Input
data
Input
data
Input
data
Lower
limit
value
Lower
limit
value
Upper
limit
value
Upper
limit
value
−NG GO +NG −NG GO +NG −NG GO +NG
왖왔
쏝
쏝
Display
(LED)
