5.6 Motor Numbering System
5.7 Drive Numbering System
Frame Size
11, 17, 23, 24, 34
Mechanical Option
A = Output shaft size
11:φ5
17:φ6
23:φ8
24:φ10
34:φ14
B = Output shaft size
17:φ5
23:φ6.35
24:φ8
Motor Size
1 = 1 stack
2 = 2 stack
3 = 3 stack
4 = 4 stack
5 = 5 stack
Step Servo
Encoder
G = 5000-Line
M = 1024-Line
D = DC Input
Note: AM17/23/24/34SS motors matching with SS-EC drive have -N suffix
AM11SS motors matching with SS-EC drive DO NOT have -N suffix
AM17 SS 1 D G A-N
Step Servo
EC = EtherCAT
Output Current
03 = 3A
05 = 5A
10 = 10A
D = Dual-port Ethernet
SS 05 - EC - D
