3 Accessory Connector
4
*
16-Position Select Knob
This knob is usually programmed for channel selection.
5 On/Off/Volume Control Knob
Rotate clockwise until you hear a click to turn on the radio.
Rotate counterclockwise until you hear a click to turn off the radio.
Rotate clockwise to increase the volume.
Rotate counterclockwise to decrease the volume.
6
*
3-Position A/B/C Switch
This switch is usually programmed for zone selection.
7 Belt Clip
8 Battery Latch
9 LED Indicator
10
*
2-Position Concentric Switch
This switch is usually programmed to enable or disable secure operation.
11
*
Top Side (Select) Button
Use this programmable button to access a programmed function or enable or disable
a feature.
12 Push-to-Talk (PTT) Button
Press and hold to talk in simplex calls or to initiate a group call, release it to listen.
13
*
Side Button 1
Use this programmable button to access a programmed function or enable or disable
a feature.
14
*
Side Button 2
Use this programmable button to access a programmed function or enable or disable
a feature.
15 Top Display
16 Microphone
17 Main Speaker
18 Bluetooth Pairing Location Indicator
19 Battery
3.2
Programmable Features
Your system administrator can program the programmable buttons as shortcuts to radio functions or
preset channels/groups depending on the duration of a button press. Some functions can also be
programmed to the radio switches.
*
These radio controls/buttons are programmable.
MN002667A01-AV
Chapter 3 : Radio Controls
18
