Installation B
High-Definition DVR DCX3510-M • Installation Manual 15
365-095-17066-x.1
Video Connection Options
Use the following guidelines to determine the best video connection for the subscriber
home entertainment system. To determine the available video inputs on the TV, check
the manual supplied with the TV or the TV itself.
The DCX3510-M offers the following video outputs:
Connection Type TV Type Options
Component
(YPbPr)
HDTV and SDTV The YPbPr output, providing three component analog video
signals to the TV, is the most widely supported HD video
connection.
HDMI or IEEE-1394
HDTV and SDTV
• HDMI and IEEE-1394 provide higher-quality digital HD
video signals than component video signals. If the TV has
an HDMI or a DVI input, use the HDMI output instead of
the IEEE-1394 output.
• HDMI and IEEE-1394 are video and audio connections. If
you use HDMI or IEEE-1394, no separate audio
connection to the TV is required.
• HDMI is compatible with DVI. If the TV has a DVI input,
you can use an HDMI-to-DVI converter cable or adapter to
connect the DVI-equipped TV to the HDMI-equipped
DCX3510-M.
• If you use the IEEE-1394 connection, the subscriber will
be unable to see on-screen graphics (such as the EPG).
Video (composite)
SDTV only The composite video is an analog video connection for SDTV
services and requires a separate audio connection.
