Connecting an A/V Receiver, SDTV, and VCR
1. Connect a stereo audio cable to the AUDIO OUT L/R connectors on the DCX3510-M
series set-top and the INPUT L/R connectors on the A/V receiver.
2. Connect a composite video cable to the composite video out connector on the
DCX3510-M series set-top and the composite video connector on the A/V receiver.
3. Connect a stereo audio cable to the VCR AUDIO OUT L/R connectors on the A/V
receiver and the INPUT AUDIO L/R connectors on the stereo VCR.
4. Connect a stereo audio cable to the OUTPUT AUDIO OUT L/R connectors on the
stereo VCR and the VCR AUDIO IN L/R connectors on the A/V receiver.
5. Connect a composite video cable to the input video connector on the stereo VCR
and the video VCR OUT connector on the A/V receiver.
6. Connect a composite video cable to the output video connector on the stereo VCR
and the video VCR IN connector on the A/V receiver.
7. Connect a Composite Video cable to the input Composite Video connector on the
Standard-Definition TV (SDTV) and the TV/monitor output Composite Video
connector on the A/V receiver.
Note: The digital audio optical (OPTICAL S/PDIF) output may be used in place of the
stereo audio outputs (AUDIO L/R). Optical S/PDIF offers a higher level of audio quality,
including support for Dolby Digital audio.
Note: These video connection methods do not support HD video. If there is an HDTV,
see Connecting an HDTV — Separate Video/Audio Connections.
