Specifications A - 9
Magstripe Reader
Vehicle Cradle
Table A-8
Magstripe Reader (MSR) Technical Specifications
Feature Description
Dimensions 8.4 cm x 9.4 cm (3.3 inches x 3.7 inches)
Weight 79.4 g (2.8 oz.)
Interface Serial with baud rate up to 19,200
Format ANSI, ISO, AAMVA, CA DMV, user-configurable generic format
Swipe Speed 5 to 50 in. (127 to 1270 mm) /sec, bi-directional
Decoders Generic, Raw Data
Mode Buffered, unbuffered
Track Reading Capabilities Tracks 1 and 3: 210 bpi
Track 2: 75 and 210 bpi, autodetect
Operating Temperature 32° to 122° F (-10° to 50° C)
Storage Temperature -40° to 158° F (-40° to 70° C)
Humidity 5% to 95% non-condensing
Drop 4 ft. (1.22 m) drops to concrete
Electrostatic Discharge (ESD) +/- 15 kV air
+/- 8 kV contact
Table A-9
Vehicle Cradle Technical Specifications
Feature Description
Dimensions Height: 10.4 cm (4.09 in.)
Width: 11.1 cm (4.37 in.)
Depth: 6.9 cm (2.72 in.)
Weight 240 g (8.47 oz)
Power 9 - 32 VDC
Operating Temperature -20°C to 50°C (-4°F to 122°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Charging Temperature 0°C to 40°C (32°C to 104°F)
Humidity 10% to 95% non-condensing
Drop 76.2 cm (30.0 in.) drops to vinyl tiled concrete at room temperature
Electrostatic Discharge (ESD) +/- 15 kV air
+/- 8 kV contact
