Chapter 1: INTRODUCTION
10
General torque specifications
Maintenance Chart
size M4 M5 M6 M8 size M10 M12 M14
Grade 4.8 in-lbs 11 22 38 93 ft-lbs 16 27 43
Nm 1.2 2.5 4.3 10.5 Nm 21.7 36.6 58
5.8 in-lbs 15 28 50 120 ft-lbs 20 35 55
Nm 1.7 3.2 5.7 13.6 Nm 27.1 47.5 76
8.8 in-lbs 26 51 88 216 ft-lbs 35 61 97
Nm 2.9 5.8 9.9 24.4 Nm 47.5 82.7 132
10.9 in-lbs 36 72 124 300 ft-lbs 49 86 136
Nm 4.1 8.1 14 33.9 Nm 66.4 116.6 184
12.9 in-lbs 44 86 146 360 ft-lbs 60 103 162
Nm 5 9.7 16.5 40.7 Nm 81.4 139.7 220
in-lbs 18 35 60 150 ft-lbs 25 45 70
Nm
2 4 6.8 17 Nm 33.9 61 95
Noncritical
Fasteners in
Aluminum
Maintenance item Each use Each 25 hrs. use Each 50 hrs. use
Check oil
*
Check air filter
(If applicable)
*
Note on air filter
Note on pre-filter
Check & gap spark plug
*
Check cooling fins
Check/clean spark
arrestor
*
Change oil *
Note on oil:
Change air filter *
Note on air filter
Drain or preserve fuel
Fog or lube cylinder
Rotate engine to TDC
Before prolonged storage
Before prolonged storage
Before prolonged storage
Change oil after first 5 hrs. of use, and before
prolonged storage.
Dirt may be shaken or tapped out of the air filter, but
compressed air is not to be used for cleaning. Do not
wash or oil paper filter element.
Foam pre-filter may be washed in water and mild
detergent, and re-used. Do not oil.
Replace if worn.
Air filter and pre-filter life vary dramatically with
operating conditions.
After prolonged storage
