MTS Exceed™ Series 40 Product Manual
32
Specifications
Introduction
Model Specifications
Specifications of Model E42
Exceed model
E42.503
Maximum rated force capacity 5 kN (1100 lbf)
Force capacity options 5 N, 10 N, 20 N, 50 N, 100 N, 200 N, 500 N, 1 kN, 2 kN,
5 kN
(1 lbf, 2 lbf, 5 lbf, 10 lbf, 20 lbf, 45 lbf, 110 lbf, 220 lbf,
450 lbf, 1100 lbf )
Frame type table-top
Test zone Single
Maximum test speed 500 mm/min
(19.7 in/min)
Minimum test speed 0.001 mm/min (0.00004 in/min)
Position resolution 0.000051 mm (0.0000022 in)
Vertical test space crosshead travel
Standard length
Extended length
700 mm (27.6 in)
1000 mm(39.4 in)
Clearance from loading axis to column cover 100 mm (3.94 in)
Frame height
Standard length
Extended length
1300 mm (51.18 in)
1600 mm(63.0 in)
Frame width 642 mm (25.28 in)
Frame depth 582 mm (22.91 in)
Weight
Standard length
Extended length
120 kg (265 lb)
130 kg (287 lb)
Power Requirements 200-230 V AC
3 Amp
50/60 Hz
600 W
1 Phase
0Exceed product manual.book Page 32 Wednesday, August 27, 2014 2:55 PM
