MTS Exceed™ Series 40 Product Manual
36
Specifications
Introduction
Dimensions
Model E42.503 - Rated Force Capacity 5 kN
178mm
(7.01 in)
100 mm
(3.94 in)
582 mm
(22.91 in)
642 mm
(25.28 in)
140 mm
(5.51 in)
278 mm
(10.94 in)
Standard height
1300 mm
(51.18 in)
Extended Length
1600 mm
(62.99 in)
0Exceed product manual.book Page 36 Wednesday, August 27, 2014 2:55 PM
