(Continued)
DescriptionField
Specify the internal port or ports by one of these methods:
• If the external and internal port or ports are identical, leave the Use the same port
range for Internal port check box selected.
• If the service or application uses a single port, enter the port number in the Internal
port range field.
• If the service or application uses a range or ranges of ports, specify the range in
the Internal port range field. Specify one range by using a dash between the port
numbers. Specify multiple ranges by separating the ranges with commas.
Internal port range
Either enter an IP address in the Internal IP address field or select the radio button
for an attached device that is listed in the table.
Internal IP address
9. Click the Apply button.
Your settings are saved. The rule is added to the table on the Port Forwarding / Port Triggering page.
Change a Port Forwarding Rule
You can change an existing port forwarding rule.
To change a port forwarding rule:
1. Launch a web browser from a computer or mobile device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the router user name and password.
The user name is admin.The default password is password.The user name and password are
case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > Advanced Setup > Port Forwarding / Port Triggering.
The Port Forwarding / Port Triggering page displays.
5. Make sure that the Port Forwarding radio button is selected.
6. In the table, select the radio button for the service or application name.
7. Click the Edit Service button.
The Ports - Custom Services page displays.
8. Change the settings.
Manage Port Forwarding and Port Triggering
118
AC1200 WiFi Router Model R6120
