Page #53 background imageLoading...
Page #53 background image
Configure WEP Legacy WiFi Security
Wired Equivalent Privacy (WEP) security is a legacy authentication and data encryption mode that is
superseded by WPA-PSK and WPA2-PSK. WEP limits the WiFi transmission speed to 54 Mbps (the router
is capable of higher speeds in the 2.4 GHz band).
If you want to change the WiFi settings of the router’s main network, use a wired connection
to avoid being disconnected when the new WiFi settings take effect.
Tip
To configure WEP security:
1. Launch a web browser from a computer or mobile device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the router user name and password.
The user name is admin.The default password is password.The user name and password are
case-sensitive.
The BASIC Home page displays.
4. Select Wireless.
The Wireless Network page displays.
If you are configuring a guest network, select Guest Network instead.The Guest
Network Settings page displays. In this situtation disregard Step 5 and go to Step 6.
Note
5. From the Mode menu, select Up to 54 Mbps.
The page adjusts to display the WEP radio button.
If you are configuring a guest network, disregard this step.Note
6. In the Security Options section, select the WEP radio button.
Manage the Basic WiFi Network Settings
53
AC1200 WiFi Router Model R6120

Table of Contents

Other manuals for NETGEAR R6120

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR R6120 and is the answer not in the manual?

NETGEAR R6120 Specifications

General IconGeneral
DSL WANNo
Ethernet WANYes
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)1200 Mbit/s
WLAN data transfer rate (first band)300 Mbit/s
WLAN data transfer rate (second band)900 Mbit/s
Product typeTabletop router
Product colorBlack
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates10, 100 Mbit/s
Ethernet LAN interface typeFast Ethernet
Memory card slot(s)-
USB 2.0 ports quantity1
Ethernet LAN (RJ-45) ports5
Power source typeAC
Antennas quantity2
Cables includedLAN (RJ-45)
Windows operating systems supportedWindows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Security algorithmsWPA, WPA2-PSK
Package depth219 mm
Package width179 mm
Package height109 mm
Package weight660 g
Shipping (inner) case width461 mm
Shipping (inner) case height215 mm
Shipping (inner) case length352 mm
Shipping (inner) case net weight4780 g
Number of layers per pallet (sea)9 pc(s)
Number of cartons per pallet layer6 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth136.5 mm
Width185 mm
Height46 mm
Weight250 g
