6. Select the By bridge group radio button.
7. Select a Wired Ports check box or a Wireless check box.
• If your device is connected to an Ethernet port on the router, select the Wired Devices check box
that corresponds to the Ethernet port on the router to which the device is connected.
• If your device is connected to your router’s WiFi network, select the Wireless check box that
corresponds to the router’s WiFi network to which the device is connected.
You must select at least one Wired Devices or Wireless check box.You can select
more than one check box.
Note
8. Click the Apply button.
Your settings are saved.
Set Up a Bridge for a VLAN Tag Group
If the devices that are connected to the router’s Ethernet LAN ports or WiFi network include an IPTV device,
your ISP might require you to set up a bridge for a VLAN tag group for the router’s Internet interface.
If you are subscribed to an IPTV service, the router might require VLAN tags to distinguish between the
Internet traffic and the IPTV traffic. A bridge with a VLAN tag group prevents packets that are sent between
the IPTV device and the router’s Internet port from being processed through the router’s Network Address
Translation (NAT) service.
You can add VLAN tag groups to a bridge and assign VLAN IDs and priority values to each VLAN tag group.
To add a VLAN tag group and enable the bridge:
1. Launch a web browser from a computer or mobile device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the router user name and password.
The user name is admin.The default password is password.The user name and password are
case-sensitive.
The BASIC Home page displays.
Manage the WAN and LAN Network Settings
94
AC1200 WiFi Router Model R6120
