NETGEAR R6120 User Manual

7. Enable or disable access methods by selecting or clearing the corresponding check boxes and specifying
access to the storage device as described in the following table.
DescriptionAccess Method
Enabled by default.You can type \\readyshare to access the storage device within
your network. If you change the name in the Network/Device Name field from
readyshare to another name, the link changes accordingly.You can enable password
protection.
Network Connection
Enabled by default.You can type http://readyshare.routerlogin.net/shares to access
the USB device within your network and download or upload files. In this URL,
readyshare is the name that is specified in the Network/Device Name field. If you
change the name in the Network/Device Name field from readyshare to another
name, the link changes accordingly.
You can also click the link that is shown in the Link column.The fixed port number is
80.You can enable password protection.
HTTP
Disabled by default. If you enable this feature, remote users can type https://<public
IP address>/shares to access the USB device over the Internet.<public IP address>
is the external or public IP address that is assigned to the router (for example,
1.1.10.102).
This feature supports file uploading only.The default port is number 443, which you
can change. Password protection is enabled by default.
HTTPS (via internet)
Enabled by default.You can type ftp://readyshare.routerlogin.net/shares to access
the USB device within your network and download or upload files. In this URL,
readyshare is the name that is specified in the Network/Device Name field. If you
change the name in the Network/Device Name field from readyshare to another
name, the link changes accordingly.
You can also click the link that is shown in the Link column.The fixed port number is
21.You can enable password protection.
FTP
Disabled by default. If you enable this feature, remote users can type ftp://<public IP
address>/shares to access the USB device over the Internet and download or upload
files. <public IP address> is the external or public IP address that is assigned to the
router (for example, 1.1.10.102).
The default port number 21, which you can change. Password protection is enabled
by default.
FTP (via internet)
8. Click the Apply button.
Your settings are saved.
Enable FTP Access Within Your Network
File Transfer Protocol (FTP) lets you download (receive) and upload (send) large files faster.
To enable FTP access within your network:
1. Launch a web browser from a computer or mobile device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
Share a Storage Device Attached to the Router
68
AC1200 WiFi Router Model R6120

NETGEAR R6120 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1200 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	900 Mbit/s
Product type	Tabletop router
Product color	Black
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Memory card slot(s)	-
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	5
Power source type	AC
Antennas quantity	2
Cables included	LAN (RJ-45)
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Security algorithms	WPA, WPA2-PSK
Package depth	219 mm
Package width	179 mm
Package height	109 mm
Package weight	660 g
Shipping (inner) case width	461 mm
Shipping (inner) case height	215 mm
Shipping (inner) case length	352 mm
Shipping (inner) case net weight	4780 g
Number of layers per pallet (sea)	9 pc(s)
Number of cartons per pallet layer	6 pc(s)

Weight and Dimensions

Depth	136.5 mm
Width	185 mm
Height	46 mm
Weight	250 g
