4-OPERATINGINSTRUCTIONS
Telescopingstabilizersandexendlinksad-
justment
Telescopingstabilizersandxedendlinksarestandard
equipmentonthetractor,theexendlinksareoptional
equipment.
Thetelescopingstabilizers(1)useapinandmultiplehole
arrangementforeasyadjustment,forsidetosidemove-
mentofthethree-pointlinkage.
Toadjustthestabilizer,pullthepin(2)andadjustthesta-
bilizerandinsertthepinintothedesiredhole.
NOTE:Cyclethethreepointlinkagethroughtheentire
travelandcheckforinterferencewiththereartires.If
interferenceispresent,adjuststabilizersasneeded.
WARNING
Machinedamagecancauseaccidents!
Onlyoperatethree-pointequipmentwithboth
exendsreturnedtothelatchedposition.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0467A
Theexends(3)onthelowerliftarmsareadjustedby
pushingdownontheclamp(4)andslidingtheendstothe
desiredlength.Oncetheimplementisattached,pushin
ontheexendsuntiltheendsareinthelatchedposition
inthearms.
NHIL13CT01019AA4
NHIL13CT01020AA5
4-13

New Holland Boomer 47 Specifications

General

Engine Power	47 hp
Transmission	Hydrostatic
Weight	2, 866 lbs
PTO Speed	540 rpm
3-Point Hitch Lift Capacity	2, 756 lbs
