3-CONTROLSANDINSTRUMENTS
Brakepedals
WARNING
Lossofcontrolhazard!
Alwaysreducethetravelingspeedandusethe
steeringwheelwhileyoumakeaturn.When
youoperatethemachineathighspeeds,never
attempttomakesharpturnsbyusingtheturn-
ingbrakepedals.Ifyouusetheindividual
brakesathighspeeds,themachinecouldbe-
comemachineunstable.
Failuretocomplycouldresultindeathorse-
riousinjury.
W1237A
Therightbrakepedalcontrolsthebrakingactionofthe
rightrearwheel.Theleftbrakepedalcontrolsthebraking
actionoftheleftrearwheel.
ThefunctionofthebrakepedalsareidenticalfortheHST
andgearmodeltractorsexceptforthelocationoftheped-
als.Thebrakepedals(1)onaHSTmodeltractorarelo-
catedontheleft-handsideoftheoperatorsplatformand
thebrakepedals(2)onagearmodeltractorarelocated
ontheright-handsideoftheoperatorsplatform.
Depressbothpedalssimultaneouslytostopthetractor.
Toassistinmakingsharpturnsatslowspeed,depress
therightorleftbrakepedalasrequired.
Thebrakepedalconnectingpin(3)isusedtosecurethe
brakepedalstogether.Lockthepedalstogetherwhen-
everthetractorisoperatedathighspeedsorwhenthe
tractorisusedonthehighway.
NHIL13CT01173AA1
NHIL13CT01055AA2
3-13
