7-MAINTENANCE

Transmissionuidlevel

NOTE:Checkthetransmission,rearaxle,andhydraulic

systemoillevelafterevery50hoursofoperation.

1.Withtheengineoffandthetractorstandinglevel,check

theoillevelusingthedipstick(1).

930993601

2.Theoilisatthecorrectlevelwhenitreadsbetweenthe

twomarks(A)onthedipstick.Ifthelevelislow,add

NEWHOLLANDAMBRAMULTIG134™HYDRAULIC

TRANSMISSIONOILhydraulicoilthroughthedipstick

hole.Donotllabovethedipstickfullmark.

3.Reinstallthedipstick.

931009042

Clutchpedalfreeplay

NOTE:Checkclutchpedalfreetravelafterevery50hoursofoperation.

ClutchpedalfreetravelshouldbemaintainedatA=20-

mm(0.79-1.18

in).

Toadjusttheclutchpedal:

1.Loosenlocknut(1)androtateadjuster(2)

2.Tighteningtheadjusterwilldecreasethefreeplaytravel

andlooseningtheadjusterwillincreasethefreeplay

travel.

3.Tightenthelocknutwhenthecorrectfreeplaytravelis

obtained

4.Checkclutchfordisengagementwhenclutchpedalis

fullydepressed.

931008621

7-19

New Holland Boomer 47 User Manual
