2-SAFETYINFORMATION
Internationalsymbols
Asaguidetotheoperationofthemachine,variousuniversalsymbolshavebeenutilizedontheinstruments,controls,
switches,andfusebox.Thesymbolsareshownbelowwithanindicationoftheirmeaning.
Thermostart
startingaid
Radio
PTO
Position
Control
Alternator
charge
Keepalive
memory
Transmission
inneutral
Draft
Control
Fuellevel
Turnsignals
Creeper
gears
Accessory
socket
Automatic
Fuelshut-off
Turnsignals
-onetrailer
Slowor
lowsetting
Implement
socket
Enginespeed
(rev/minx100)
Turnsignals
-twotrailers
Fastorhigh
setting
%age
slip
Hoursrecorded
Frontwind-
shield
wash/wipe
Ground
speed
Hitchraise
(rear)
Engineoil
pressure
Rearwind-
shield
wash/wipe
Differential
lock
Hitchlower
(rear)
Enginecoolant
temperature
Heatertemp-
eraturecontrol
Rearaxle
oiltem-
perature
Hitchheight
limit(rear)
Coolant
level
Heaterfan
Transmission
oilpressure
Hitchheight
limit(front)
Tractorlights
Airconditioner
FWD
engaged
Hitchdis-
abled
Headlamp
mainbeam
Airlter
blocked
FWDdis-
engaged
Hydraulicand
transmission
lters
Headlamp
dippedbeam
Parking
brake
Warning!
Remote
valveextend
Worklamps
Brakeuid
level
Hazard
warninglights
Remote
valveretract
Stop
lamps
Trailer
brake
Variable
control
Remote
valveoat
Horn
Roof
beacon
Pressurized!
Opencarefully
Malfunction!
SeeOperator's
Manual
Warning!
Corrosive
substance
Malfunction!
(alter-
nativesymbol)
2-34

New Holland Boomer 47 Specifications

General

Engine Power	47 hp
Transmission	Hydrostatic
Weight	2, 866 lbs
PTO Speed	540 rpm
3-Point Hitch Lift Capacity	2, 756 lbs
