New Holland Boomer 47 User Manual

3-CONTROLSANDINSTRUMENTS
Hydraulichoseconnection
WARNING
Crushinghazard!
Beforedisconnectingthecylindersorequip-
ment,makesureyouadequatelysupportand
securetheequipmentorimplement.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0243A
WARNING
Escapinguid!
Remotecouplersmustbeproperlymounted
andsecurelyfastenedtothemachinemount-
ingbracketforproperfunctioningofthesafety
disconnectfeature.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0131A
Whenconnectinghydraulichoses,followtheinstructions
listedbelow.
•
Loaderdown/retractcylinder,yellowcoupler(1).
•
Loaderup/extendcylinder,greencoupler(2).
•
Bucketcurl/retractcylinder,redcoupler(3).
•
Bucketdump/extendcylinder,bluecoupler(4).
NHIL13CT00921AA3
3-33

New Holland Boomer 47 Specifications

General

Engine Power	47 hp
Transmission	Hydrostatic
Weight	2, 866 lbs
PTO Speed	540 rpm
3-Point Hitch Lift Capacity	2, 756 lbs
