14
11) Technical characteristics
Mains power supply A60 : 230 Vac 50/60 Hz
A60/V1 : 120 Vac 50/60 Hz
Max current for 24 V services : 200mA (the voltage may vary ± 25%)
Maximum actuator power : two 400 VA motors (2A) approx. 1/2 Hp.
Flashing light output : For flashing lights at mains voltage, maximum power 40 W
“SCA” open gate telltale light output : For 24 Vac telltale lights, maximum power 2 W
Operating temperature : -20 ÷70 °C
Working Time (TL1) and (TL2) : Adjustable from 2.5 to >40 s, or from <40 to >80 s with TLM
Pause Time (TP) : Adjustable from 5 to >80 sec.
Opening Time Delay (TRA) : 0 or 2.5 to 12 sec.
Closing Time Delay (TRC) : 0 or 2.5 to 12 sec.
Dimensions : 280 x 220 x 110
Protection class : IP 55
