TECHNICAL SPECIFICATIONS OF PRODUCT
PP7224
Electromechanical gearmotor for automations of gates and
automatic doors with DC motor, epicyclical gear reducer and
mechanical release.
PP7124
Electromechanical gearmotor for automations of gates and
automatic doors with DC motor, epicyclical gear reducer
and mechanical release. Built-in control unit and OXI radio
receiver.
Type
Maximum torque 250 Nm
Rated torque 100 Nm
Speed under no load 0,17 rad/s (1,6 rpm)
Speed at rated torque 0,13 rad/s (1,2 rpm)
Maximum cycle frequency * 35 cycles/hour
Maximum time of continuous 10 minutes
cycle **
Application limits the product can be used on gates with leaf weight up to 200 kg for lengths up to 2 m
Lifetime estimated between 80.000 cycles and 250.000 cycles, depending on the conditions reported in Table 15 and Graph 3
Assembly Vertical, with dedicated fixing plate
Operating temperature from -20°C to +50°C (at low temperatures, gearmotor efficiency is reduced)
Use in acid, saline
or potentially explosive NO
atmospheres
IP protection rating IP 44 (with container intact)
Dimensions (mm) 167 x 254 x 315 h
Weight (kg) 10 9
[*]
Cycle frequency at maximum temperature: 25 cycles/hour
[
**] Maximum continuous cycle time at maximum temperature: 8 minutes
[***] The outputs Flashing Light and Electric lock can be programmed with other functions (see “TABLE 5 – Level 1 functions”; or via the Oview programmer; see chapter 8.3). The elec-
trical specifications of the output are adapted to the type of selected function: • flashing light function: lamp 12 V , 21 W max; • electric lock function: 12 V 15 VA max; • other
outputs (all types): 1 lamp or relay 24V (-30 to +50%), max. 4 W.
Power supply 230 V (120 V for version PP7124/V1) 24 V (±25%)
±10%; 50/60 Hz
Back-up power supply provision for buffer battery PS124
Solar power provision for SYKCE kit
Maximum power absorption 170 W 50 W
at rated torque
Peak power 280 W 100 W
Rated current absorption 0,8 A (1,6 A for version PP7124/V1)2 A
Maximum current absorption 1,3 A (2,6 A for version PP7124/V1) 4 A (for maximum time of 1 s)
Absorbed power with
“All – Standby” function when
powered by PS124 or SYKCE less than 100 mW
kit (including OXI receiver)
Flashing light output *** one LUCYB flashing light (12 V , 21 W)
Electric lock output *** one electric lock, 12 V max 15 VA
BLUEBUS output one output with load of maximum 15 Bluebus units
(max. 6 pairs of MOFB or MOFOB photocells plus 2 pairs
of MOFB or MOFOB photocells routed as opening devices
plus max. 4 MOMB or MOTB control devices)
STOP input for normally closed contacts, normally open contacts
or contacts with constant 8,2 kΩ resistance; selection
of the type of contact is in self-learning mode and
a modification with respect to the memorised status
will generate a “STOP” command
SS input for normally open contacts (closure of the contact
generates a Step Step command)
OPEN input for normally open contacts (closure of the
contact generates a Partial Open 1 command)
Radio engage SM connector for receivers in the families SMXI,
OXI and OXIFM
Radio AERIAL input 50 Ω for cable type RG58 or similar
Programmable functions 8 ON-OFF type functions (Table 5) and 8 settable
functions (Table 6)
Self-learning • Self-learning of devices connected to the BlueBus output
Functions • Self-learning of the type of device connected
to the “STOP” terminal (NO, NC contact or 8,2 kΩ)
• Self-learning of the gate leaf travel
and automatic calculation of deceleration
points and partial opening. • Self-learning of operation
with one or two motors
WARNINGS: • All technical specifications stated in this section refer to an ambient temperature of 20°C (± 5°C). • Nice S.p.a. reserves the right to apply modifi-
cations to products at any time when deemed necessary, maintaining the same intended use and functionality.
