Network configuration
Configuring Upstream (US) Classifier
3FE-49441-ABAA-TCZZA
Issue 1
Table 8-23 US Classifier parameters (continued)
Field Description
Source IP Click to enter a source IP address.
Destination IP Click to enter a destination IP address.
Source Port Click to enter a source port.
Destination Port Click to enter a destination port.
Protocol Click to enter a protocol.
Priority Select a priority level from 1 to 8. The lower the number, the higher the priority. No more
than 1 classifier can be created with the same priority.
6
Click Save.
Click Reset to reset the classifier configured.
Click Refresh to view the up-to-date information.
Click Delete for the applicable classifier in the classifier table, to delete a classifier.
Note: A classifier can only be deleted if it is not associated with any classifier rules.
7
Select the Classifier Rules tab.
All classifier rules are displayed in the classifier rules table in the page.
