G-2426G-B LEDs
3FE-49441-ABAA-TCZZA
Issue 1
Table 5-7 G-2426G-B indoor ONT LED descriptions (continued)
Indicator LED color and behavior LED behavior description
PON Off No fiber connected or no rx power
Green solid ONT has been configured on the OLT and is in service (UP)
Flashing Green ONT is attempting to range with OLT
solid Red GPON is down or no link connected.
INTERNET Solid Green HSI WAN is connected with the either of the two possibilities:
• the device has an IP address assigned from IPCP, DHCP, or static
• the session is dropped due to idle timeout but the PON link is still present, or
transmit and receive traffic is ongoing
Green Flashing PPPoE or DHCP connection is in progress.
Off(Dark) HSI WAN is not connected due to the following reasons:
• there is no physical interface connection
• the device is inbridged mode without an assigned IP address
• the session has been dropped for reasons other than idle time-out.
TEL Solid Green One Phone is off hook and VOIP service is built up.
Flashing Green Phone is in ‘call in’ or ‘talking’ condition.
Red VOIP service is out of service.
Off All phones are on hook, VOIP service is not built up.
WPS Solid Green Wi-Fi protected setup link is up (negotiation and auto-configuration successful)
Flashing Green Wi-Fi protected setup link activity (negotiation and auto-configuration ongoing)
Red Solid Wi-Fi protected setup processing exception or multiple peers using WPS
simultaneously
Off
Wi-Fi protected setup link down or no link connected (negotiation has not started or
has failed)
WLAN Solid Green Wi-Fi enabled for at least 1 RF
Off(dark) WLAN is down
LAN /RJ45 Green Executed on the RJ45 connectors
Solid green Lan link active
OFF LAN link if OFF or LOS
USB Solid Green A device is connected to the USB port .
Off(dark) No device connected to the USB port.
Flashing green Traffic activity on the USB connection
