4 Enabling User Access (Level 2)
4.1 Passcode Entry
With the Status Normal screen displayed on the LCD, pressing the
key will present the user access level passcode request entry
screen.
Entry of a valid passcode enables the user to access the appropriate
panel menus. Which menu is displayed next depends upon the
access passcode entered: user or commissioning level.
To enter the access Level 2 passode make sure that ‘Standard
User’ is highlighted and then press the
key. The screen now
presents the user with a passcode entry eld. Using the numeric
keypad enter the appropriate access passcode and press the
key again to enter.
A correct passcode entry displays the main user level menu (Main
Menu).
Press the
key to abandon an invalidated passcode entry attempt
and re-try the passcode entry. Press the key and repeat the
process above.
4.2 Keyswitch Entry
Similarly, inserting the access entry key into the keyswitch and
turning it clockwise through 90° will display the access Level 2 Main
Menu. The MENU tab at the bottom of the screen conrms this.
Note:
The MENU tab is also present when the passcode entry
screen is displayed.
Note:
In the unlikely event that the required user access passcode
has been forgotten and the key has been misplaced, contact
the servicing company for assistance. You will asked to quote
the code displayed when the key is pressed. No other
method is available to access the menus in this situation.
