Page #131 background imageLoading...
Page #131 background image
131
EN
Playback
3
Protecting Pictures (0)
Protect images from accidental deletion. Display the
image you want to protect and press the 0 (AEL/AFL)
button to add 0 to the image (protection icon). Press the
0 (AEL/AFL) button again to cancel protection. You
can also protect multiple selected images. g “Selecting
Multiple Pictures (0, Copy Select, Erase Selected, Share
Order Selected)” (P. 133)
Formatting the card erases all data including protected
images.
0 (protect) icon
2020.02.15 12:30:00
20
100
%
100-0020
4:3
YFYF
When an unprotected image is displayed, you can hold the 0 (AEL/AFL) button and
rotate the front or rear dial to protect all images displayed while the dial is rotated. Any
previously-protected images displayed while the dial is rotated will be unaffected.
When a protected image is displayed, you can hold the 0 (AEL/AFL) button and
rotate the front or rear dial to remove protection from all images displayed while the dial
is rotated. Any previously-unprotected images displayed while the dial is rotated will be
unaffected.
The same operations can be performed during playback zoom or when a picture is
selected in the index display.
Copying an image (Copy)
When there are cards with available space in both slots 1 and 2, you can copy an
image to the other card.
1
Display an image you want to copy and press the Q button.
2
Highlight [Copy] and press the Q button.
3
Choose whether to specify the destination folder.
If you select [Assign], choose a destination folder.
4
Highlight [Yes] and press the Q button.
The picture will be copied to the other card.
You can also copy all images on a card to the other card at a time. g q Playback
Menu > [Copy All] (P. 175)

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Olympus E-M1 Mark III and is the answer not in the manual?

Olympus E-M1 Mark III Specifications

General IconGeneral
Megapixel20.4 MP
Camera typeMILC
Sensor typeMOS
Image stabilizerYes
Total megapixels21.8 MP
Image sensor size- \
Image formats supportedJPEG, RAW
Supported aspect ratios4:3
Maximum image resolution5184 x 3888 pixels
Image sensor size (W x H)17.4 x 13 mm
Still image resolution(s)5184 x 3888, 1024 x 768
FocusTTL
Focus adjustmentAuto/Manual
Auto Focus (AF) points121
Auto focusing (AF) modesContinuous Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance0.15 m
Normal focusing range (tele)- m
Auto Focus (AF) points selectionAuto, Manual
Filter size72 mm
Digital zoom- x
Focal length range12 - 100 mm
Lens mount interfaceMicro Four Thirds (MFT)
Maximum aperture number4
Minimum aperture number22
Number of diaphragm blades7
Number of aspheric elements3
Lens structure (elements/groups)17/11
Maximum focal length (35mm film equiv)200 mm
Minimum focal length (35mm film equiv)24 mm
PictBridge-
USB version3.2 Gen 1 (3.1 Gen 1)
USB connectorUSB Type-C
Headphone outputs1
HDMI connector typeMicro
Headphone connectivity3.5 mm
Magnification1.48 x
Viewfinder typeElectronic
Display diagonal3 \
Display resolution1037000 dot
Display aspect ratio3:2
Memory slots2
Compatible memory cardsSD, SDHC, SDXC
Audio systemstereo
Audio formats supportedPCM
Cables includedUSB
Video resolutions1280 x 720, 1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Video recording time29 min
Video formats supportedAVC, H.264, MOV, MPEG4
Maximum video resolution4096 x 2160 pixels
Resolution at capture speed1280x720@24fps, 1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1280x720@60fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps, 3840x2160@24fps, 3840x2160@25fps, 3840x2160@30fps, 4096x2160@24fps
Flash modesAuto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed1/250 s
Shoe mounting point typeHot shoe
Flash exposure correction±3EV (1/2, 1/3, 1 EV step)
Quantity per pack1 pc(s)
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)-10 - 40 °C
Storage relative humidity (H-H)10 - 90 %
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/32000 s
Slowest camera shutter speed60 s
Battery typeBLH-1
Battery life (max)1.4 h
Battery life (CIPA standard)420 shots
ISO sensitivity64, 100, 200, 6400, 25600
ISO sensitivity (max)25600
ISO sensitivity (min)64
Product colorBlack
Freezeproof up to-10 °C
International Protection (IP) codeIPX1
Eye relief21 mm
Scene modesPortrait, Underwater
Image editingTrimming
Photo effectsBlack&White, Vivid
White balanceAuto, Custom modes
Shooting modesAuto
Camera playbackMovie, Single image
Self-timer delay- s
Camera file systemDCF 2.0, DPOF, Exif 2.31
Diopter adjustment (D-D)-4 - 2
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version4.2
Weight and Dimensions IconWeight and Dimensions
Depth68.9 mm
Width134.1 mm
Height90.9 mm
Weight504 g
Lens length116.5 mm
Lens weight561 g
Lens diameter77.5 mm
Weight (including battery)580 g
