Olympus E-M1 Mark III User Manual

91 EN
Shooting
2
Changing ISO sensitivity (ISO)
You can set the ISO sensitivity. g “Changing ISO sensitivity (ISO)” (P. 75)
• Separate options can be selected for still photography and movie mode.
1
Press the Q button to display the LV super control
panel.
2
Use FGHI to select [ISO].
3
Use the front dial to select an option.
ISO
sRGB
Natural
S
Normal
WB
Auto
ISO
Auto
M-IS
± 0
A ± 0
± 0 ± 0
± 0
G ± 0
P
250
1023
1:02:03
F5.6
p
#
± 0.0
#
o
S-IS Auto
30
p
30
p
4K
Y
F
Y
F
S - AF
100 %
Off
K
Recommended ISO
Choosing a focus mode (AF Mode)
You can select a focusing method (focus mode). g “Choosing a focus mode (AF
Mode)” (P. 64)
• Separate options can be selected for still photography and movie mode.
1
Press the Q button to display the LV super control
panel.
2
Use FGHI to select [AF Mode].
3
Use the front dial to select an option.
AF Mode
sRGB
Natural
S
Normal
WB
Auto
ISO
Auto
M-IS
± 0
A ± 0
± 0 ± 0
± 0
G ± 0
P
250
1023
1:02:03
F5.6
p
#
± 0.0
#
o
S-IS Auto
30
p
30
p
4K
Y
F
Y
F
S - AF
100 %
Off
K
AF Mode
Positioning and Sizing the AF Target (AF Area)
Choose an AF target. g “Choosing an AF Target Mode (AF Target Mode)” (P. 69),
“Choosing a Focus Target (AF Target Point)” (P. 72)
1
Press the Q button to display the LV super control
panel.
2
Highlight [AF Area] using FGHI on the arrow
pad and press the Q button.
• AF-target selection options will be displayed.
3
Use the front or rear dial to choose an AF-target
mode and FGHI to position the AF target.
AF Area
sRGB
Natural
S
Normal
WB
Auto
ISO
Auto
M-IS
± 0
A ± 0
± 0 ± 0
± 0
G ± 0
P
250
1023
1:02:03
F5.6
p
#
± 0.0
#
o
S-IS Auto
30
p
30
p
4K
Y
F
Y
F
S - AF
100 %
Off
AF Area

Olympus E-M1 Mark III Specifications

General

Megapixel	20.4 MP
Camera type	MILC
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	21.8 MP
Image sensor size	- \
Image formats supported	JPEG, RAW
Supported aspect ratios	4:3
Maximum image resolution	5184 x 3888 pixels
Image sensor size (W x H)	17.4 x 13 mm
Still image resolution(s)	5184 x 3888, 1024 x 768
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	121
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance	0.15 m
Normal focusing range (tele)	- m
Auto Focus (AF) points selection	Auto, Manual
Filter size	72 mm
Digital zoom	- x
Focal length range	12 - 100 mm
Lens mount interface	Micro Four Thirds (MFT)
Maximum aperture number	4
Minimum aperture number	22
Number of diaphragm blades	7
Number of aspheric elements	3
Lens structure (elements/groups)	17/11
Maximum focal length (35mm film equiv)	200 mm
Minimum focal length (35mm film equiv)	24 mm
PictBridge	-
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector	USB Type-C
Headphone outputs	1
HDMI connector type	Micro
Headphone connectivity	3.5 mm
Magnification	1.48 x
Viewfinder type	Electronic
Display diagonal	3 \
Display resolution	1037000 dot
Display aspect ratio	3:2
Memory slots	2
Compatible memory cards	SD, SDHC, SDXC
Audio system	stereo
Audio formats supported	PCM
Cables included	USB
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Video recording time	29 min
Video formats supported	AVC, H.264, MOV, MPEG4
Maximum video resolution	4096 x 2160 pixels
Resolution at capture speed	1280x720@24fps, 1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1280x720@60fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps, 3840x2160@24fps, 3840x2160@25fps, 3840x2160@30fps, 4096x2160@24fps
Flash modes	Auto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed	1/250 s
Shoe mounting point type	Hot shoe
Flash exposure correction	±3EV (1/2, 1/3, 1 EV step)
Quantity per pack	1 pc(s)
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/32000 s
Slowest camera shutter speed	60 s
Battery type	BLH-1
Battery life (max)	1.4 h
Battery life (CIPA standard)	420 shots
ISO sensitivity	64, 100, 200, 6400, 25600
ISO sensitivity (max)	25600
ISO sensitivity (min)	64
Product color	Black
Freezeproof up to	-10 °C
International Protection (IP) code	IPX1
Eye relief	21 mm
Scene modes	Portrait, Underwater
Image editing	Trimming
Photo effects	Black&White, Vivid
White balance	Auto, Custom modes
Shooting modes	Auto
Camera playback	Movie, Single image
Self-timer delay	- s
Camera file system	DCF 2.0, DPOF, Exif 2.31
Diopter adjustment (D-D)	-4 - 2
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.2

Weight and Dimensions

Depth	68.9 mm
Width	134.1 mm
Height	90.9 mm
Weight	504 g
Lens length	116.5 mm
Lens weight	561 g
Lens diameter	77.5 mm
Weight (including battery)	580 g
