165
EN
Menu functions (Video menu)
4
Choosing an Exposure Mode (n Mode (Movie Exposure Modes))
You can create movies that take advantage of the effects available in P, A, S, and M
modes. This option takes effect when the mode dial is rotated to n.
1
Select [n Mode Settings] in n Video Menu and press the Q button.
2
Select [n Mode] (movie exposure modes) and press I.
3
Use FG to select an option and press the Q button.
P
Optimal aperture is set automatically according to the brightness of the subject.
Use the front dial or rear dial to adjust exposure compensation.
A
Depiction of background is changed by setting the aperture.
Use the front dial to adjust exposure compensation and rear dial to adjust aperture.
S
Shutter speed affects how the subject appears. Use the front dial to adjust exposure
compensation and rear dial to adjust shutter speed.
Shutter speed can be set to values between 1/24 s and 1/32000 s.
M
Freely adjust both aperture and shutter speed.
Use the front dial to select aperture value and the rear dial to select shutter speed.
Choose from shutter speeds of 1/24–1/32000 s. Values of ISO 200–6400 are
available using the [n ISO] manual sensitivity control options.
The display shows the difference between the exposure produced by the selected
aperture and shutter speed and the optimal exposure metered by the camera. The
display will ash if the difference exceeds ±3 EV.
The option chosen for [n Speci cation Settings] > [b ISO-Auto Set] (P. 161)
takes effect.
Blurred frames caused by such factors as the subject moving while the shutter is open
can be reduced by selecting the fastest available shutter speed.
The low end of the shutter speed changes according to the frame rate of the movie record
mode.
Excessive camera shake may not be compensated enough.
When the inside of the camera becomes hot, shooting is automatically stopped to protect
the camera.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Olympus E-M1 Mark III and is the answer not in the manual?

Olympus E-M1 Mark III Specifications

General IconGeneral
Megapixel20.4 MP
Camera typeMILC
Sensor typeMOS
Image stabilizerYes
Total megapixels21.8 MP
Image sensor size- \
Image formats supportedJPEG, RAW
Supported aspect ratios4:3
Maximum image resolution5184 x 3888 pixels
Image sensor size (W x H)17.4 x 13 mm
Still image resolution(s)5184 x 3888, 1024 x 768
FocusTTL
Focus adjustmentAuto/Manual
Auto Focus (AF) points121
Auto focusing (AF) modesContinuous Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance0.15 m
Normal focusing range (tele)- m
Auto Focus (AF) points selectionAuto, Manual
Filter size72 mm
Digital zoom- x
Focal length range12 - 100 mm
Lens mount interfaceMicro Four Thirds (MFT)
Maximum aperture number4
Minimum aperture number22
Number of diaphragm blades7
Number of aspheric elements3
Lens structure (elements/groups)17/11
Maximum focal length (35mm film equiv)200 mm
Minimum focal length (35mm film equiv)24 mm
PictBridge-
USB version3.2 Gen 1 (3.1 Gen 1)
USB connectorUSB Type-C
Headphone outputs1
HDMI connector typeMicro
Headphone connectivity3.5 mm
Magnification1.48 x
Viewfinder typeElectronic
Display diagonal3 \
Display resolution1037000 dot
Display aspect ratio3:2
Memory slots2
Compatible memory cardsSD, SDHC, SDXC
Audio systemstereo
Audio formats supportedPCM
Cables includedUSB
Video resolutions1280 x 720, 1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Video recording time29 min
Video formats supportedAVC, H.264, MOV, MPEG4
Maximum video resolution4096 x 2160 pixels
Resolution at capture speed1280x720@24fps, 1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1280x720@60fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps, 3840x2160@24fps, 3840x2160@25fps, 3840x2160@30fps, 4096x2160@24fps
Flash modesAuto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed1/250 s
Shoe mounting point typeHot shoe
Flash exposure correction±3EV (1/2, 1/3, 1 EV step)
Quantity per pack1 pc(s)
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)-10 - 40 °C
Storage relative humidity (H-H)10 - 90 %
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/32000 s
Slowest camera shutter speed60 s
Battery typeBLH-1
Battery life (max)1.4 h
Battery life (CIPA standard)420 shots
ISO sensitivity64, 100, 200, 6400, 25600
ISO sensitivity (max)25600
ISO sensitivity (min)64
Product colorBlack
Freezeproof up to-10 °C
International Protection (IP) codeIPX1
Eye relief21 mm
Scene modesPortrait, Underwater
Image editingTrimming
Photo effectsBlack&White, Vivid
White balanceAuto, Custom modes
Shooting modesAuto
Camera playbackMovie, Single image
Self-timer delay- s
Camera file systemDCF 2.0, DPOF, Exif 2.31
Diopter adjustment (D-D)-4 - 2
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version4.2
Weight and Dimensions IconWeight and Dimensions
Depth68.9 mm
Width134.1 mm
Height90.9 mm
Weight504 g
Lens length116.5 mm
Lens weight561 g
Lens diameter77.5 mm
Weight (including battery)580 g
