296
EN
Information
7
Shooting tips and information
The camera does not turn on even when a battery is loaded
The battery is not fully charged
Charge the battery with the charger.
The battery is temporarily unable to function because of the cold
Battery performance drops at low temperatures. Remove the battery and warm it by
putting it in your pocket for a while.
No picture is taken when the shutter button is pressed
The camera has turned off automatically
If [On] is selected for [Quick Sleep Mode] (P. 199), the camera will enter sleep mode if
no operations are performed for a set period. Press the shutter button halfway to exit the
sleep mode.
The camera automatically enters sleep mode to reduce the drain on the battery if no
operations are performed for a set period of time. g G Custom Menu c > [Sleep]
(P. 199)
If no operations are performed for a set time after the camera has entered sleep mode,
the camera will turn off automatically. g G Custom Menu c > [Auto Power Off]
(P. 199)
The ash is charging
On the monitor, the # mark blinks when charging is in progress. Wait for the blinking to
stop, then press the shutter button.
Unable to focus
The camera cannot focus on subjects that are too close to the camera or that are not
suited to autofocus (the AF con rmation mark will blink in the monitor). Increase the
distance to the subject or focus on a high contrast object at the same distance from the
camera as your main subject, compose the shot, and shoot.
Subjects that are dif cult to focus on
It may be dif cult to focus with auto focus in the following situations.
AF con rmation
mark is blinking.
These subjects
are not focused.
Subject with low
contrast
Excessively bright
light in center of frame
AF con rmation
mark lights up but
the subject is not
focused.
Subjects at different
distances
Fast-moving subject Subject not inside
AF area

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Olympus E-M1 Mark III and is the answer not in the manual?

Olympus E-M1 Mark III Specifications

General IconGeneral
Megapixel20.4 MP
Camera typeMILC
Sensor typeMOS
Image stabilizerYes
Total megapixels21.8 MP
Image sensor size- \
Image formats supportedJPEG, RAW
Supported aspect ratios4:3
Maximum image resolution5184 x 3888 pixels
Image sensor size (W x H)17.4 x 13 mm
Still image resolution(s)5184 x 3888, 1024 x 768
FocusTTL
Focus adjustmentAuto/Manual
Auto Focus (AF) points121
Auto focusing (AF) modesContinuous Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance0.15 m
Normal focusing range (tele)- m
Auto Focus (AF) points selectionAuto, Manual
Filter size72 mm
Digital zoom- x
Focal length range12 - 100 mm
Lens mount interfaceMicro Four Thirds (MFT)
Maximum aperture number4
Minimum aperture number22
Number of diaphragm blades7
Number of aspheric elements3
Lens structure (elements/groups)17/11
Maximum focal length (35mm film equiv)200 mm
Minimum focal length (35mm film equiv)24 mm
PictBridge-
USB version3.2 Gen 1 (3.1 Gen 1)
USB connectorUSB Type-C
Headphone outputs1
HDMI connector typeMicro
Headphone connectivity3.5 mm
Magnification1.48 x
Viewfinder typeElectronic
Display diagonal3 \
Display resolution1037000 dot
Display aspect ratio3:2
Memory slots2
Compatible memory cardsSD, SDHC, SDXC
Audio systemstereo
Audio formats supportedPCM
Cables includedUSB
Video resolutions1280 x 720, 1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Video recording time29 min
Video formats supportedAVC, H.264, MOV, MPEG4
Maximum video resolution4096 x 2160 pixels
Resolution at capture speed1280x720@24fps, 1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1280x720@60fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps, 3840x2160@24fps, 3840x2160@25fps, 3840x2160@30fps, 4096x2160@24fps
Flash modesAuto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed1/250 s
Shoe mounting point typeHot shoe
Flash exposure correction±3EV (1/2, 1/3, 1 EV step)
Quantity per pack1 pc(s)
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)-10 - 40 °C
Storage relative humidity (H-H)10 - 90 %
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/32000 s
Slowest camera shutter speed60 s
Battery typeBLH-1
Battery life (max)1.4 h
Battery life (CIPA standard)420 shots
ISO sensitivity64, 100, 200, 6400, 25600
ISO sensitivity (max)25600
ISO sensitivity (min)64
Product colorBlack
Freezeproof up to-10 °C
International Protection (IP) codeIPX1
Eye relief21 mm
Scene modesPortrait, Underwater
Image editingTrimming
Photo effectsBlack&White, Vivid
White balanceAuto, Custom modes
Shooting modesAuto
Camera playbackMovie, Single image
Self-timer delay- s
Camera file systemDCF 2.0, DPOF, Exif 2.31
Diopter adjustment (D-D)-4 - 2
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version4.2
Weight and Dimensions IconWeight and Dimensions
Depth68.9 mm
Width134.1 mm
Height90.9 mm
Weight504 g
Lens length116.5 mm
Lens weight561 g
Lens diameter77.5 mm
Weight (including battery)580 g
