Olympus E-M1 Mark III User Manual

172 EN
Menu functions (Playback menu)
4
Combining Pictures (Image Overlay)
Overlay existing RAW photos and to create a new picture. Up to 3 pictures can be
included in the overlay.
The results can be modifi ed by adjusting brightness (gain) separately for each picture.
• The overlay is saved in the format currently selected for image quality. Overlays created
with [RAW] selected for image quality are saved in RAW format and in JPEG format using
the image quality option selected for [K2] (P. 194).
• Overlays saved in RAW format can in turn be combined with other RAW images to create
overlays containing 4 or more pictures.
1
Select [Edit] in the q Playback Menu and press the Q button.
2
Use FG to select [Image Overlay] and press the Q button.
3
Select the number of images to be overlaid and press the Q button.
4
Use FGHI to select the RAW images to be
overlaid.
• Selected pictures are marked with a v. To deselect,
press the Q button again.
• The overlaid image will be displayed if images of the
number specifi ed in step 3 are selected.
5
Adjust the gain for each image to be overlaid.
• Use HI to select an image and FG to adjust gain.
• Gain can be adjusted in the range 0.1 – 2.0. Check the
results in the monitor.
6
Press the Q button to display the confi rmation
dialog.
• Select [Yes] and press the Q button.
RAW RAW RAW
RAW
RAW RAW RAW
100 %
Image Overlay
Back
Set
×1.5×1.5×0.3 ×0.5
100 %
Image Overlay
Back
Set

Olympus E-M1 Mark III Specifications

General

Megapixel	20.4 MP
Camera type	MILC
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	21.8 MP
Image sensor size	- \
Image formats supported	JPEG, RAW
Supported aspect ratios	4:3
Maximum image resolution	5184 x 3888 pixels
Image sensor size (W x H)	17.4 x 13 mm
Still image resolution(s)	5184 x 3888, 1024 x 768
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	121
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance	0.15 m
Normal focusing range (tele)	- m
Auto Focus (AF) points selection	Auto, Manual
Filter size	72 mm
Digital zoom	- x
Focal length range	12 - 100 mm
Lens mount interface	Micro Four Thirds (MFT)
Maximum aperture number	4
Minimum aperture number	22
Number of diaphragm blades	7
Number of aspheric elements	3
Lens structure (elements/groups)	17/11
Maximum focal length (35mm film equiv)	200 mm
Minimum focal length (35mm film equiv)	24 mm
PictBridge	-
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector	USB Type-C
Headphone outputs	1
HDMI connector type	Micro
Headphone connectivity	3.5 mm
Magnification	1.48 x
Viewfinder type	Electronic
Display diagonal	3 \
Display resolution	1037000 dot
Display aspect ratio	3:2
Memory slots	2
Compatible memory cards	SD, SDHC, SDXC
Audio system	stereo
Audio formats supported	PCM
Cables included	USB
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Video recording time	29 min
Video formats supported	AVC, H.264, MOV, MPEG4
Maximum video resolution	4096 x 2160 pixels
Resolution at capture speed	1280x720@24fps, 1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1280x720@60fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps, 3840x2160@24fps, 3840x2160@25fps, 3840x2160@30fps, 4096x2160@24fps
Flash modes	Auto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed	1/250 s
Shoe mounting point type	Hot shoe
Flash exposure correction	±3EV (1/2, 1/3, 1 EV step)
Quantity per pack	1 pc(s)
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/32000 s
Slowest camera shutter speed	60 s
Battery type	BLH-1
Battery life (max)	1.4 h
Battery life (CIPA standard)	420 shots
ISO sensitivity	64, 100, 200, 6400, 25600
ISO sensitivity (max)	25600
ISO sensitivity (min)	64
Product color	Black
Freezeproof up to	-10 °C
International Protection (IP) code	IPX1
Eye relief	21 mm
Scene modes	Portrait, Underwater
Image editing	Trimming
Photo effects	Black&White, Vivid
White balance	Auto, Custom modes
Shooting modes	Auto
Camera playback	Movie, Single image
Self-timer delay	- s
Camera file system	DCF 2.0, DPOF, Exif 2.31
Diopter adjustment (D-D)	-4 - 2
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.2

Weight and Dimensions

Depth	68.9 mm
Width	134.1 mm
Height	90.9 mm
Weight	504 g
Lens length	116.5 mm
Lens weight	561 g
Lens diameter	77.5 mm
Weight (including battery)	580 g
