81
EN
Shooting
2
Shooting without shutter sound (Silent s)
In situations where the shutter sound is a problem, you can shoot without making a
sound. An electronic shutter is used to reduce the minuscule camera shake caused by
the motion of the mechanical shutter, much as is the case for anti-shock photography.
The delay between the shutter button being pressed all the way down and the shutter
being released can be selected using [Anti-Shock r/Silent s] > [Silent s] in
X Shooting Menu 2 (P. 157).
1
Press the jY# button.
2
Select one of the items marked using the rear dial and press the Q button.
3
Take pictures.
When the shutter is released, the monitor screen will go dark for a moment. No
shutter sound will be emitted.
The desired results may not be achieved under ickering light sources such as uorescent
or LED lamps or if the subject moves abruptly during shooting.
The fastest available shutter speed is 1/32000 s.
Shooting without a release time lag (Pro Capture shooting)
Capture starts when the shutter button is pressed halfway; the moment the button
is pressed the rest of the way down, the camera will start saving the last n captured
pictures to the memory card, where n is a number selected before shooting begins. If
the button is held all the way down, shooting will continue until the selected number
of pictures is recorded. Use this option to capture moments you might otherwise miss
due to your subject’s reactions or shutter lag. Choose from [Pro Capture Low] and [Pro
Capture High].
Shutter button pressed
halfway
Shutter lag
Up to 35 frames
Burst shooting
continues
Shutter button pressed all
the way down
Moment you
want

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Olympus E-M1 Mark III and is the answer not in the manual?

Olympus E-M1 Mark III Specifications

General IconGeneral
Megapixel20.4 MP
Camera typeMILC
Sensor typeMOS
Image stabilizerYes
Total megapixels21.8 MP
Image sensor size- \
Image formats supportedJPEG, RAW
Supported aspect ratios4:3
Maximum image resolution5184 x 3888 pixels
Image sensor size (W x H)17.4 x 13 mm
Still image resolution(s)5184 x 3888, 1024 x 768
FocusTTL
Focus adjustmentAuto/Manual
Auto Focus (AF) points121
Auto focusing (AF) modesContinuous Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance0.15 m
Normal focusing range (tele)- m
Auto Focus (AF) points selectionAuto, Manual
Filter size72 mm
Digital zoom- x
Focal length range12 - 100 mm
Lens mount interfaceMicro Four Thirds (MFT)
Maximum aperture number4
Minimum aperture number22
Number of diaphragm blades7
Number of aspheric elements3
Lens structure (elements/groups)17/11
Maximum focal length (35mm film equiv)200 mm
Minimum focal length (35mm film equiv)24 mm
PictBridge-
USB version3.2 Gen 1 (3.1 Gen 1)
USB connectorUSB Type-C
Headphone outputs1
HDMI connector typeMicro
Headphone connectivity3.5 mm
Magnification1.48 x
Viewfinder typeElectronic
Display diagonal3 \
Display resolution1037000 dot
Display aspect ratio3:2
Memory slots2
Compatible memory cardsSD, SDHC, SDXC
Audio systemstereo
Audio formats supportedPCM
Cables includedUSB
Video resolutions1280 x 720, 1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Video recording time29 min
Video formats supportedAVC, H.264, MOV, MPEG4
Maximum video resolution4096 x 2160 pixels
Resolution at capture speed1280x720@24fps, 1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1280x720@60fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps, 3840x2160@24fps, 3840x2160@25fps, 3840x2160@30fps, 4096x2160@24fps
Flash modesAuto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed1/250 s
Shoe mounting point typeHot shoe
Flash exposure correction±3EV (1/2, 1/3, 1 EV step)
Quantity per pack1 pc(s)
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)-10 - 40 °C
Storage relative humidity (H-H)10 - 90 %
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/32000 s
Slowest camera shutter speed60 s
Battery typeBLH-1
Battery life (max)1.4 h
Battery life (CIPA standard)420 shots
ISO sensitivity64, 100, 200, 6400, 25600
ISO sensitivity (max)25600
ISO sensitivity (min)64
Product colorBlack
Freezeproof up to-10 °C
International Protection (IP) codeIPX1
Eye relief21 mm
Scene modesPortrait, Underwater
Image editingTrimming
Photo effectsBlack&White, Vivid
White balanceAuto, Custom modes
Shooting modesAuto
Camera playbackMovie, Single image
Self-timer delay- s
Camera file systemDCF 2.0, DPOF, Exif 2.31
Diopter adjustment (D-D)-4 - 2
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version4.2
Weight and Dimensions IconWeight and Dimensions
Depth68.9 mm
Width134.1 mm
Height90.9 mm
Weight504 g
Lens length116.5 mm
Lens weight561 g
Lens diameter77.5 mm
Weight (including battery)580 g
