Olympus E-M1 Mark III User Manual

203 EN
Menu functions (Custom menus)
4
C-AF Tracking Sensitivity (K C-AF Sensitivity)
MENU G J [K C-AF Sensitivity]
Choose how rapidly the camera responds to changes in the distance to the subject
while focusing with [C-AF], [C-AFb], [C-AF+TR], or [C-AF+TRb] selected for
[K AF Mode]. This can help autofocus track a quickly-moving subject or prevent the
camera refocusing when an object passes between the subject and the camera.
• Choose from fi ve levels of tracking sensitivity.
• The higher the value, the higher the sensitivity. Choose positive values for subjects that
suddenly enter the frame, that are moving rapidly away from the camera, or that change
speed or stop suddenly while moving toward or away from the camera.
• The lower the value, the lower the sensitivity. Choose negative values to prevent the
camera refocusing when the subject is briefl y obscured by other objects or to prevent the
camera focusing on the background when you are unable to keep the subject in the AF
target.
1
Highlight [K C-AF Sensitivity] in G Custom Menu
J and press the Q button.
1
2
A2
A3
A4
B1
B2
C1
C2
A1
A1
A1. AF/MF
mode2
±0
S3/C4/M3/F3
Off
S-AF
100 %
AF Scanner
K
AEL/AFL
K
AF+MF
K
AF Mode
K
C-AF Sensitivity
K
C-AF Center Start
K
C-AF Center Priority
Back
Set
2
Highlight a setting using the FG buttons and
press the Q button.
• G Custom Menu J will be displayed.
1
2
A2
A3
A4
B1
B2
C1
C2
A1
A1
A1. AF/MF
mode2
±0
S3/C4/M3/F3
Off
S-AF
100 %
AF Scanner
K
AEL/AFL
K
AF+MF
K
AF Mode
K
C-AF Sensitivity
K
C-AF Center Start
K
C-AF Center Priority
Back
Set
+2
+1
0
±0
- 1
- 2
High
Low
3
Press the MENU button repeatedly to exit the menus.

Olympus E-M1 Mark III Specifications

General

Megapixel	20.4 MP
Camera type	MILC
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	21.8 MP
Image sensor size	- \
Image formats supported	JPEG, RAW
Supported aspect ratios	4:3
Maximum image resolution	5184 x 3888 pixels
Image sensor size (W x H)	17.4 x 13 mm
Still image resolution(s)	5184 x 3888, 1024 x 768
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	121
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance	0.15 m
Normal focusing range (tele)	- m
Auto Focus (AF) points selection	Auto, Manual
Filter size	72 mm
Digital zoom	- x
Focal length range	12 - 100 mm
Lens mount interface	Micro Four Thirds (MFT)
Maximum aperture number	4
Minimum aperture number	22
Number of diaphragm blades	7
Number of aspheric elements	3
Lens structure (elements/groups)	17/11
Maximum focal length (35mm film equiv)	200 mm
Minimum focal length (35mm film equiv)	24 mm
PictBridge	-
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector	USB Type-C
Headphone outputs	1
HDMI connector type	Micro
Headphone connectivity	3.5 mm
Magnification	1.48 x
Viewfinder type	Electronic
Display diagonal	3 \
Display resolution	1037000 dot
Display aspect ratio	3:2
Memory slots	2
Compatible memory cards	SD, SDHC, SDXC
Audio system	stereo
Audio formats supported	PCM
Cables included	USB
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Video recording time	29 min
Video formats supported	AVC, H.264, MOV, MPEG4
Maximum video resolution	4096 x 2160 pixels
Resolution at capture speed	1280x720@24fps, 1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1280x720@60fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps, 3840x2160@24fps, 3840x2160@25fps, 3840x2160@30fps, 4096x2160@24fps
Flash modes	Auto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed	1/250 s
Shoe mounting point type	Hot shoe
Flash exposure correction	±3EV (1/2, 1/3, 1 EV step)
Quantity per pack	1 pc(s)
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/32000 s
Slowest camera shutter speed	60 s
Battery type	BLH-1
Battery life (max)	1.4 h
Battery life (CIPA standard)	420 shots
ISO sensitivity	64, 100, 200, 6400, 25600
ISO sensitivity (max)	25600
ISO sensitivity (min)	64
Product color	Black
Freezeproof up to	-10 °C
International Protection (IP) code	IPX1
Eye relief	21 mm
Scene modes	Portrait, Underwater
Image editing	Trimming
Photo effects	Black&White, Vivid
White balance	Auto, Custom modes
Shooting modes	Auto
Camera playback	Movie, Single image
Self-timer delay	- s
Camera file system	DCF 2.0, DPOF, Exif 2.31
Diopter adjustment (D-D)	-4 - 2
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.2

Weight and Dimensions

Depth	68.9 mm
Width	134.1 mm
Height	90.9 mm
Weight	504 g
Lens length	116.5 mm
Lens weight	561 g
Lens diameter	77.5 mm
Weight (including battery)	580 g
