Olympus E-M1 Mark III User Manual

290 EN
Cautions
6
 Wireless Flash Control Range
The illustration is intended as a guide only. The fl ash control range varies with the type
of fl ash mounted on the camera and the conditions in the surrounding area.
Flash Control Range for Camera-Mounted FL-LM3 Flash Units
7m
5m
100°100°
50°
50°
50°
50°
60°
60°
30°
30°
30°
30°
• We recommend that each group contain no more than 3 fl ash units.
• Wireless fl ash photography is not available in anti-shock mode or in rear-curtain slow sync
mode when a shutter speed slower than 4 s is selected.
• Start wait times longer than 4 s cannot be selected in anti-shock and silent modes.
• Flash control signals may interfere with exposure if subject is too close to the camera.
This can be mitigated by reducing the brightness of the camera fl ash, for example by
using a diffuser.
Other external fl ash units
Note the following when using a third-party fl ash unit mounted on the camera hot shoe:
• Using obsolete fl ash units that apply currents of more than about 250 V to the X-contact
will damage the camera.
• Connecting fl ash units with signal contacts that do not conform to Olympus specifi cations
may damage the camera.
• Select mode M, choose a shutter speed no faster than the fl ash sync speed, and set
[K ISO] to [AUTO].
• Flash control can only be performed by manually setting the fl ash to the ISO sensitivity
and aperture values selected with the camera. Flash brightness can be adjusted by
adjusting either ISO sensitivity or aperture.
• Use a fl ash with an angle of illumination suited to the lens. Angle of illumination is usually
expressed using 35-mm format equivalent focal lengths.

Olympus E-M1 Mark III Specifications

General

Megapixel	20.4 MP
Camera type	MILC
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	21.8 MP
Image sensor size	- \
Image formats supported	JPEG, RAW
Supported aspect ratios	4:3
Maximum image resolution	5184 x 3888 pixels
Image sensor size (W x H)	17.4 x 13 mm
Still image resolution(s)	5184 x 3888, 1024 x 768
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	121
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance	0.15 m
Normal focusing range (tele)	- m
Auto Focus (AF) points selection	Auto, Manual
Filter size	72 mm
Digital zoom	- x
Focal length range	12 - 100 mm
Lens mount interface	Micro Four Thirds (MFT)
Maximum aperture number	4
Minimum aperture number	22
Number of diaphragm blades	7
Number of aspheric elements	3
Lens structure (elements/groups)	17/11
Maximum focal length (35mm film equiv)	200 mm
Minimum focal length (35mm film equiv)	24 mm
PictBridge	-
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector	USB Type-C
Headphone outputs	1
HDMI connector type	Micro
Headphone connectivity	3.5 mm
Magnification	1.48 x
Viewfinder type	Electronic
Display diagonal	3 \
Display resolution	1037000 dot
Display aspect ratio	3:2
Memory slots	2
Compatible memory cards	SD, SDHC, SDXC
Audio system	stereo
Audio formats supported	PCM
Cables included	USB
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Video recording time	29 min
Video formats supported	AVC, H.264, MOV, MPEG4
Maximum video resolution	4096 x 2160 pixels
Resolution at capture speed	1280x720@24fps, 1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1280x720@60fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps, 3840x2160@24fps, 3840x2160@25fps, 3840x2160@30fps, 4096x2160@24fps
Flash modes	Auto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed	1/250 s
Shoe mounting point type	Hot shoe
Flash exposure correction	±3EV (1/2, 1/3, 1 EV step)
Quantity per pack	1 pc(s)
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/32000 s
Slowest camera shutter speed	60 s
Battery type	BLH-1
Battery life (max)	1.4 h
Battery life (CIPA standard)	420 shots
ISO sensitivity	64, 100, 200, 6400, 25600
ISO sensitivity (max)	25600
ISO sensitivity (min)	64
Product color	Black
Freezeproof up to	-10 °C
International Protection (IP) code	IPX1
Eye relief	21 mm
Scene modes	Portrait, Underwater
Image editing	Trimming
Photo effects	Black&White, Vivid
White balance	Auto, Custom modes
Shooting modes	Auto
Camera playback	Movie, Single image
Self-timer delay	- s
Camera file system	DCF 2.0, DPOF, Exif 2.31
Diopter adjustment (D-D)	-4 - 2
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.2

Weight and Dimensions

Depth	68.9 mm
Width	134.1 mm
Height	90.9 mm
Weight	504 g
Lens length	116.5 mm
Lens weight	561 g
Lens diameter	77.5 mm
Weight (including battery)	580 g
