Omron 3G3JX Quick Start Guide

10 JX Quick Start Guide
INSTALLATION
2.7 Digital inputs SINK/SOURCE (NPN/PNP) settings
Digital
output
signals
AL2
NC output
Factory default relay settings
Under normal operation: AL2-AL0 closed
Under abnormal operation: AL1-AL0 open
250 VAC 2.5 A
30 VDC 3 A
AL1
NO output
250 VAC 1 A
30 VDC 1 A
5 V, 100 mA min
AL0
Relay output common
11
Multi-function output terminal Factory setting: Frequency arrival signal at a constant speed
27 VDC
50 mA max
CM2
Output signal common 
Monitor
signal
AM
Analog frequency monitor/Analog output current monitor Factory setting: Analog frequency monitor 0 to 10 VDC, 1 mA
Sinking internal supply (for NPN outputs) Sinking external supply (for NPN outputs)
Sourcing internal supply (for PNP outputs) Sourcing external supply (for PNP outputs)
P24
PCS
L
1
5
24 V DC
Inverter
Short-circuit
bar
COM
+V
Output unit etc.
P24
PCS
L
1
5
24 V DC
Inverter
COM
DC24V
+V
Output unit etc.
P24
PCS
L
1
5
24 V DC
Inverter
Short-circuit
bar
COM
0V
Output unit etc.
P24
PCS
L
1
5
24 V DC
Inverter
COM
24 V DC
0V
Output unit etc.

Omron 3G3JX Specifications

General

Model	3G3JX
Category	Inverter
Control Method	V/f control
Input Frequency	50/60 Hz
Communication Interface	RS-485 (optional)
Operating Temperature	-10 to 50°C
Humidity	20 to 90% RH (non-condensing)
Enclosure Rating	IP20
Input Voltage	200 to 240 V AC
Output Voltage	Three-phase 200 to 240 V AC
Output Frequency	400 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	RS-485
Braking Unit	Built-in
Power Range	0.1 to 15 kW
Cooling Method	Fan-cooled
Storage Temperature	-20°C to +65°C
Altitude	Up to 1000 m
