Omron 3G3JX Quick Start Guide

JX Quick Start Guide 3
JX Quick Start Guide
1 SPECIFICATIONS
1.1 Upon receipt
Please perform the following task after receiving the drive:
• Inspect the driver for damage. If the drive appear damage upon receipt, contact your supplier.
• Verify the receipt of the correct model by checking the information on the nameplate. If you have received the wrong model contact your
supplier.
• Refer to the User’s Manual for detailed information about the product and functions.
Basic specifications and optional EMC filter
1.2 Power ratings
Vo lta ge
Type
Max Motor (KW) Rated output current (A)
EMC filter
3G3JX-
1 x 200 V
AB002 0.2
1.4
AX-FIJ1006-RE
AB004 0.4
2.6
AB007 0.75
4.0 AX-FIJ1010-RE
AB015 1.5
7.1
AX-FIJ1026-RE
AB022 2.2
10.0
3 x 200 V
A2002 0.2
1.4
AX-FIJ2006-RE
A2004 0.4
2.6
A2007 0.75
4.0
A2015 1.5
7.1
AX-FIJ2020-RE
A2022 2.2
10.0
A2037 3.7
15.9
A2055 5.5
24.0
AX-FIJ2040-RE
A2075 7.5
32.0
3 x 400 V
A4004 0.4 1.5
AX-FIJ3005-RE
A4007 0.75 2.5
A4015 1.5 3.8
A4022 2.2 5.5
AX-FIJ3011-RE
A4040 4.0 8.6
A4055 5.5 13.0
AX-FIJ3020-RE
A4075 7.5 16.0
Single-phase 200 V: 3G3JX- AB002 AB004 AB007 AB015 AB022 - - -
Three-phase 200 V: 3G3JX- A2002 A2004 A2007 A2015 A2022 A2037 A2055 A2075
Motor (kW) Applicable motor capacity 0.2 0.4 0.75 1.5 2.2 3.7 5.5 7.5
Output
characteristics
Inverter capacity (KVA)
200 V 0.4 0.9 1.3 2.4 3.4 5.5 8.3 11.0
240 V 0.5 1.0 1.6 2.9 4.1 6.6 9.9 13.3
Rated output current (A) 1.4 2.6 4.0 7.1 10.0 15.9 24.0 32.0
Max. output voltage Proportional to input voltage: 0 to 240 V
Max. output frequency 400 Hz
Power supply
Rated input voltage and frequency
Single-phase 200 to 240 V 50/60 Hz
Three-phase 200 to 240 V 50/60 Hz
Rated input current (A) single-phase 200 V 3.1 5.8 9.0 16.0 22.5 - - -
Rated input current (A) three-phase 200 V 1.8 3.4 5.2 9.3 13.0 20.0 30.0 40.0
Allowable voltage fluctuation -15% to +10%
Allowable frequency fluctuation +5%
Built-in filter EMC filter (C1 single phase)
Braking torque
At short-time deceleration
At capacitor feedback
Approx. 50%
50% for
3-phase
20 to 40% for
1-phase
Approx. 20% to 40% Approx. 20%
Cooling method Self cooling Forced-air-cooling

Omron 3G3JX Specifications

General

Model	3G3JX
Category	Inverter
Control Method	V/f control
Input Frequency	50/60 Hz
Communication Interface	RS-485 (optional)
Operating Temperature	-10 to 50°C
Humidity	20 to 90% RH (non-condensing)
Enclosure Rating	IP20
Input Voltage	200 to 240 V AC
Output Voltage	Three-phase 200 to 240 V AC
Output Frequency	400 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	RS-485
Braking Unit	Built-in
Power Range	0.1 to 15 kW
Cooling Method	Fan-cooled
Storage Temperature	-20°C to +65°C
Altitude	Up to 1000 m
