JX Quick Start Guide 31
PARAMETER LIST
4.4 Parameter group C
Parameter
No.
Function name Monitoring or data range (digital operator)
Default
setting
Changes
during
operation
Unit
Modbus
address
(hex)
C001 Multi-function input 1 selection 00: FW (forward)
01: RV (reverse)
02: CF1 (multi-step speed setting binary 1)
03: CF2 (multi-step speed setting binary 2)
04: CF3 (multi-step speed setting binary 3)
05: CF4 (multi-step speed setting binary 4)
06: JG (jogging)
07: DB (external DC injection braking)
08: SET (2nd control)
09: 2CH (2-step acceleration/deceleration)
11: FRS (free-run stop)
12: EXT (external trip)
13: USP (USP function)
15: SFT (soft lock)
16: AT (analog input switching)
18: RS (reset)
19: PTC (thermistor input)
20: STA (3-wire start)
21: STP (3-wire stop)
22: F/R (3-wire forward/reverse)
23: PID (PID enabled/disabled)
24: PIDC (PID integral reset)
27: UP (UP/DWN function accelerated)
28: DWN (UP/DWN function decelerated)
29: UDC (UP/DWN function data clear)
31: OPE (forced operator)
50: ADD (frequency addition)
51: F-TM (forced terminal block)
52: RDY (ready function)
53: SP-SET (special 2nd function)
64: EMR (emergency shutoff
*1
)
255: No function
*1. The EMR is set forcibly with switch S8, not with parameters.
00 No – 1103
C201 2nd multi-function input 1 selection 00 1532
C002 Multi-function input 2 selection 01 1104
C202 2nd multi-function input 2 selection 01 1533
C003 Multi-function input 3 selection 18 1105
C203 2nd multi-function input 3 selection 18 1534
C004 Multi-function input 4 selection 12 1106
C204 2nd multi-function input 4 selection 12 1535
C005 Multi-function input 5 selection 02 1107
C205 2nd multi-function input 5 selection 02 1536
C011 Multi-function input 1 operation selection 00: NO
01: NC
00 No – 110B
C012 Multi-function input 2 operation selection 110C
C013 Multi-function input 3 operation selection 110D
C014 Multi-function input 4 operation selection 110E
C015 Multi-function input 5 operation selection 110F
C021 Multi-function output terminal 11 selection 00: RUN (signal during RUN)
01: FA1 (constant speed arrival signal)
02: FA2 (over set frequency arrival signal)
03: OL (overload warning)
04: OD (excessive PID deviation)
05: AL (alarm output)
06: Dc (disconnection detection)
07: FBV (PID FB status output)
08: NDc (network error)
09: LOG (logic operation output)
10: ODc (do not use)
43: LOC (light load detection signal)
00 No – 1114
C026 Relay output (AL2, AL1) function selection 05 1119
C028 AM selection 00: Output frequency
01: Output current
00 No – 111B
C031 Multi-function output terminal 11 contact
selection
00: NO contact at AL2, NC contact at AL1
01: NC contact at AL2, NO contact at AL1
00 No – 111D
C036 Relay output (AL2, AL1) contact selection 01 1122
C038 Light load signal output mode 00: Enabled during acceleration/deceleration/constant
speed
01: Enabled only during constant speed
01 No – 1178
C039 Light load detection level 0.0 to 2.0 x Rated current (0.0 setting: function disable) Rated
current
No – 1179
C041 Overload warning level 0.0: Does not operate
0.1 x Rated current to 2.0 x Rated current
Rated
current
No A 1124
C241 2nd overload warning level 153A
C042 Arrival frequency during acceleration 0.0 to 400.0 0.0 No Hz 1126
C043 Arrival frequency during deceleration 1128
C044 PID deviation excessive level 0.0 to 100.0 3.0 No % 1129
C052 PID FB upper limit 0.0 to 100.0 100.0 No % 112E
C053 PID FB lower limit 0.0 112F
C070 Operator/Modbus selection 02: Digital Operator
03: Modbus
02 No – 1137
C071 Communication speed selection (Baud rate
selection)
04: 4800 bps
05: 9600 bps
06: 19200 bps
04 No – 1137
C072 Communication station No. selection 1. to 32. 1. No – 1139
