JX Quick Start Guide 29
PARAMETER LIST
4.3 Parameter group B
A093 Deceleration time 2 0.01 to 3000. 15.00 Yes s 1076 (high)
1077 (low)
A293 2nd deceleration time 2
151B (high)
151C (low)
A094 2-step accel/decel selection 00: Switched via multi-function input 09 (2CH)
01: Switched by setting
00 No – 1078
A294 2nd 2-step accel/decel selection
151D
A095 2-step acceleration frequency 0.0 to 400.0 0.0 No Hz 107A
A295 2nd 2-step acceleration frequency
151F
A096 2-step deceleration frequency 0.0 to 400.0 0.0 No Hz 107C
A296 2nd 2-step deceleration frequency
1521
A097 Acceleration pattern selection 00: Line
01: S-shape curve
00 No – 107D
A098 Deceleration pattern setting 107E
A101 OI start frequency 0.0 to 400.0 0.0 No Hz 1080
A102 OI end frequency 1082
A103 OI start ratio 0. to 100. 0. No % 1083
A104 OI end ratio 100. 1084
A105 OI start selection 00: Use OI start frequency [A101]
01: 0 Hz start
01 No – 1085
A141 Operation frequency input A setting 00: Digital operator (F001)
01: Digital operator (FREQ adjuster)
02: Input O
03: Input OI
04: RS485 communication
01 No - 108E
A142 Operation frequency input B setting 02 108F
A143 Operator selection 00: Addition (A + B)
01: Subtraction (A - B)
03: Multiplication (A x B)
00 No – 1090
A145 Frequency addition amount 0.0 to 400.0 0.0 Yes Hz 1091
A146 Frequency addition direction 00: Adds A145 value to output frequency
01: Subtract A145 value from output frequency
00 No – 1093
A151 VR start frequency 0.0 to 400.0 0.0 No Hz 1095
A152 VR end frequency 1097
A153 VR start ratio 0. to 100. 0. No % 1098
A154 VR end ratio 100. 1099
A155 VR start selection 00: Use VR start frequency [A151]
01: 0 Hz start
01 No – 109A
Parameter
No.
Function name Monitoring or data range (digital operator)
Default
setting
Changes
during
operation
Unit
Modbus
address
(hex)
b001 Retry selection 00: Alarm
01: 0 Hz start
02: Frequency matching start
03: Trip after frequency matching deceleration stop
00 No – 10A5
b002 Allowable momentary power interruption time 0.3 to 25.0 1.0 No s 10A6
b003 Retry wait time 0.3 to 100.0 1.0 No s 10A7
b004 Momentary power interruption/undervoltage trip
during stop selection
00: Disabled
01: Enabled
00 No – 10A8
b005 Momentary power interruption retry time
selection
00: 16 times
01: No limit
00 No – 10A9
b011 Starting frequency at active frequency matching
restart
00: Frequency at interruption
01: Max. frequency
02: Set frequency
00 No – 1170
b012 Electronic thermal level 0.2 x Rated current to 1.0 x Rated current Rated
current
No A 10AD
b212 2nd electronic thermal level 1527
b013 Electronic thermal characteristics selection 00: Reduced torque characteristics 1
01: Constant torque characteristics
02: Reduced torque characteristics 2
00 No – 10AE
b213 2nd electronic thermal characteristics selection 1528
b021 Overload limit selection 00: Disabled
01: Enabled in acceleration/constant speed operation
02: Enabled in constant speed operation
01 No – 10B5
b221 2nd overload limit selection 1529
b022 Overload limit level 0.1 x Rated current to 1.5 x Rated current 1.5 x
Rated
current
No A 10B6
b222 2nd overload limit level 152A
b023 Overload limit parameter 0.1 to 3000.0 1.0 No s 10B7
b223 2nd overload limit parameter 152B
b028 Overload limit source selection 00: b022, b222 set values
01: Input terminal O
00 No – 10BB
b228 2nd overload limit source selection 152C
b029 Deceleration rate constant at active frequency
matching restart level
0.1 to 3000.0 0.5 No s 1171
b030 Active frequency matching restart level 0.2 x Rated current to 2.0 x Rated current Rated
current
No A 1172
Parameter
No.
Function name Monitoring or data range (digital operator)
Default
setting
Changes
during
operation
Unit
Modbus
address
(hex)
To Next Page
