3. Instructions
CS/CJ/NSJ Series Instructions Reference Manual (W474)
Conversion Instructions
3
STR4/STR8/STR16
Function
z STR4
STR4(601) converts the numerical data in S
(4-digit hexadecimal, #0000 to #FFFF) to
ASCII data (4 characters) and writes the result
to D and D+1.
z STR8
STR8(602) converts the numerical data in S
and S+1 (8-digit hexadecimal, #0000 0000 to
#FFFF FFFF) to ASCII data (8 characters) and
writes the result to D, D+1, D+2, and D+3.
z STR16
STR16(603) converts the numerical data in S
to S+3 (16-digit hexadecimal, #0000 0000
0000 0000 to #FFFF FFFF FFFF FFFF) to
ASCII data (16 characters) and writes the
result to D to D+7.
1 2 4 3
31 32
33 34
15 8 7 0
15 8 7 0 11 12 3 4
D+1
D
ASCII
Hexadecimal: #1234
S
1 2 4 3
31 32
33 34
ASCII
5 6 8 7
35 36
37 38
15 8 7 11 12 3 4 0
15 8 7 0
D+1
D+2
D+3
D
Hexadecimal: #12345678
S
S+1
8 9 B A
30 31
32 33
C D F E
34 35
36 37
4 5 7 6
38 39
41 42
43 44
45 46
0 1 2 3
15 8 7 11 12 3 4 0
15 8 7 0
ASCII
D+1
D+2
D+3
D+4
D+5
D+6
D+7
D
S
S+1
S+2
S+3
Hexadecimal: #1234567890ABCDEF
