3. Instructions
722
CS/CJ/NSJ Series Instructions Reference Manual (W474)
CLI
Applicable Program Areas
Operands
(1) Clearing/Retaining Recorded Interrupt Causes for I/O Interrupts or Input Interrupts
Instruction Mnemonic Variations
Function
code
Function
CLEAR INTERRUPT CLI @CLI 691
Clears/retains recorded interrupt inputs, sets the
time to the first scheduled interrupt for scheduled
interrupt tasks.
Symbol
CLI
Area
Function block
definitions
Block program areas Step program areas Subroutines Interrupt tasks
SFC action or
transition programs
Usage OK OK OK OK OK OK
Operand Description Data type Size
N Interrupt number --- 1
C Control data UINT 1
Operand Contents
N
Interrupt input Interrupt identifier
Inputs to a CS1W-INT01 or CJ1W-INT01
Interrupt Input Unit (16 inputs/Unit)
0: Unit number 0
I/O interrupts 0 to 15 (interrupt tasks 100 to 115)
1: Unit number 1
I/O interrupts 16 to 31 (interrupt tasks 116 to 131)
Inputs to a C200HS-INT01 Interrupt Input
Unit (8 inputs/Unit)
0: Unit number 0
I/O interrupts 0 to 7 (interrupt tasks 100 to 107)
1: Unit number 1
I/O interrupts 8 to 15 (interrupt tasks 108 to 115)
2: Unit number 2
I/O interrupts 16 to 23 (interrupt tasks 116 to 123)
3: Unit number 3
I/O interrupts 24 to 31 (interrupt tasks 124 to 131)
Inputs to a CJ1M-CPU2@ CPU Unit's Built-in
Inputs (4 inputs/Unit)
6: Interrupt input 0 (interrupt task 140)
7: Interrupt input 1 (interrupt task 141)
8: Interrupt input 2 (interrupt task 142)
9: Interrupt input 3 (interrupt task 143)
CJ2M CPU Unit inputs (when Pulse I/O
Module is mounted) (4 inputs/Block)
100: Input interrupt 0 (interrupt task 140)
101: Input interrupt 1 (interrupt task 141)
102: Input interrupt 2 (interrupt task 142)
103: Input interrupt 3 (interrupt task 143)
104: Input interrupt 4 (interrupt task 144)
105: Input interrupt 5 (interrupt task 145)
106: Input interrupt 6 (interrupt task 146)
107: Input interrupt 7 (interrupt task 147)
Note For input interrupts 0 to 3, 6 to 9 can also be used as the interrupt number.
N: Interrupt identifier
C: Control data
CLI(691)
N
C
