140
Built-in Inputs Section 6-1
Procedure
1,2,3... 1. High-speed Counter Enable/Disable Setting (Required)
Set the High-speed Counter 0 Enable/Disable setting to 1 or 2 (use high-
speed counter) in the PLC Setup.
2. Pulse Input Mode Setting (Required)
Set the High-speed Counter 0 Pulse Input Mode in the PLC Setup.
3. Counting Mode Setting (Required)
Set the High-speed Counter 0 Counting Mode in the PLC Setup.
If ring mode counting is selected, set the High-speed Counter 0 Ring
Counter Maximum Value (max. ring count) in the PLC Setup.
4. Reset Method Setting (Required)
Set the High-speed Counter 0 Reset Method in the PLC Setup.
5. Execute PRV2 as described below (required).
Converting the Frequency to a Rotational Speed
Execute PRV2 with the following operands.
C: Control data (Set to #0000 for frequency-rotational speed conversion.)
P: Pulses/rotation (hex)
D: First word for result
Converting the Counter PV to the Total Number of Rotations
Execute PRV2 with the following operands.
C: Control data (Set to #0001 for counter PV-total number of rotations con-
version.)
P: Pulses/rotation (hex)
D: First word for result
Restrictions Pulse frequency conversion is possible only for high-speed counter 0.
6-1-5 Quick-response Inputs
Overview
The quick-response inputs read pulses with an ON time shorter than the cycle
time (as short as 30
µs). Use the quick-response inputs to read signals such
as inputs from a photomicrosensor.
Procedure
Select quick-response inputs.
Wire inputs.
PLC Setup settings
IN0 to IN3 (CIO 2960 bits 00 to 03)
Connect to the selected terminals
between IN0 and IN3.
When IN0 to IN3 are used as quick response inputs,
make the necessary "input operation settings" for
IN0 to IN3 in Programming Console address 60.
IN0: Set the rightmost digit (bits 00 to 03) to 2 Hex.
IN1: Set the second digit (bits 04 to 07) to 2 Hex.
IN2: Set the third digit (bits 08 to 11) to 2 Hex.
IN3: Set the leftmost digit (bits 12 to 15) to 2 Hex.
Use the quick-response inputs in
instructions such as LD.
Ladder program
