Omron CJ1M-CPU22 User Manual

57
PLC Setup Settings Section 4-2
Input Operation Setting for IN3
Note When IN3 is set as an interrupt input (1 hex), use the MSKS(690) instruction
to select direct mode or counter mode operation.
Input Time Constant Setting for the General-purpose Inputs
4-2-2 Origin Search Function
The following tables show the settings for the origin search function in the CX-
Programmer. These settings are for CJ1M CPU Units equipped with the built-
in I/O functions.
Note CX-Programmer Tabs
CX-Programmer Ver. 3.1 or lower: Define Origin Operation Settings Field of
Define Origin
CX-Programmer Ver. 3.2 or higher: Pulse Output 0
Programming
Console setting
address
Settings Default Function Related
Auxiliary
Area flags/
bits
Time when
setting is read
by CPU Unit
Word Bits
60 12 to 15 0 hex:
Normal (General-
purpose input)
1 hex:
Interrupt (Inter-
rupt input) (See
note.)
2 hex:
Quick (Quick-
response input)
0 hex Specifies the kind of input that is
being received at built-in input IN3
Note The input operation setting for
IN3 is disabled when high-
speed counter 0 is being used
and the reset method is set to
Phase-Z signal + software
reset.
--- When power is
turned ON
Programming
Console setting
address
Settings Default Function Related
Auxiliary
Area flags/
bits
Time when
setting is read
by CPU Unit
Word Bits
61 00 to 07 00 hex: Default
(8 ms)
10 hex: 0 ms
(no filter)
11 hex: 0.5 ms
12 hex: 1 ms
13 hex: 2 ms
14 hex: 4 ms
15 hex: 8 ms
16 hex: 16 ms
17 hex: 32 ms
0 hex Specifies the input time constant for
general-purpose inputs IN0 to IN9.
Note This setting has no effect on
inputs set as interrupt inputs,
quick-response inputs, or
high-speed counters.
--- When operation
starts
