Omron CJ1M-CPU22 User Manual

26
Wiring Section 3-2
High-speed Counters Using Up/Down Pulse Inputs
High-speed Counters Using Increment Pulse Inputs
Built-in Outputs
General-purpose Outputs
Input number Code Pin No. Content
High-speed counter 0 IN8 25 Increment input, 24 V
29 Increment input, 0 V
IN9 26 Decrement input, 24 V
30 Decrement input, 0 V
IN3 8 Reset input, 24 V
12 Reset input, 0 V
High-speed counter 1 IN6 19 Increment input, 24 V
23 Increment input, 0 V
IN7 20 Decrement input, 24 V
24 Decrement input, 0 V
IN2 7 Reset input, 24 V
11 Reset input, 0 V
Input number Code Pin No. Content
High-speed counter 0 IN8 25 Count input, 24 V
29 Count input, 0 V
IN3 8 Reset input, 24 V
12 Reset input, 0 V
High-speed counter 1 IN6 19 Count input, 24 V
23 Count input, 0 V
IN2 7 Reset input, 24 V
11 Reset input, 0 V
Output number Code Pin No. Content
General-purpose output 0 OUT0 31 Output 0
37 Power supply input
(+V) for the output
39 or 40 Output COM
General-purpose output 1 OUT1 32 Output 1
37 Power supply input
(+V) for the output
39 or 40 Output COM
General-purpose output 2 OUT2 33 Output 2
37 Power supply input
(+V) for the output
39 or 40 Output COM
General-purpose output 3 OUT3 34 Output 3
37 Power supply input
(+V) for the output
39 or 40 Output COM
General-purpose output 4 OUT4 35 Output 4
37 Power supply input
(+V) for the output
39 or 40 Output COM
