Omron E5CN-H Communications Manual

Com Data
for Modbus
SECTION 6 Communications Data for Modbus
6-14
1500 3500 PID 1 Proportional Band Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.1 to 999.9)
PID setting
1502 3501 PID 1 Integral Time Standard, heating/cooling, position proportional (closed):
H'00000000 to H'00007E90 (0.0 to 3240.0)
Position proportional (floating): H'00000001 to H'00007E90 (0.1 to 3240.0)
1504 3502 PID 1 Derivative Time H'00000000 to H'00007E90 (0.0 to 3240.0)
1506 3503 PID 1 MV Upper Limit Standard: MV lower limit +0.1 to H'0000041A (MV lower limit +0.1 to 105.0)
Heating/cooling: H'00000000 to H'0000041A (0.0 to 105.0)
Position proportional (closed): MV lower limit +0.1 to H'0000041A
(MV lower limit +0.1 to 105.0)
1508 3504 PID 1 MV Lower Limit Standard: H'FFFFFFCE to MV upper limit −0.1
(
−5.0 to MV upper limit −0.1)
Heating/cooling: H'FFFFFBE6 to H'00000000 (
−105.0 to 0.0)
Position proportional (closed): H'FFFFFFCE to MV upper limit
−0.1
(
−5.0 to MV upper limit −0.1)
150A 3505 PID 1 Automatic Selection Range
Upper Limit
Temperature: H'FFFFB1E1 to H'00007E90 (
−19999 to 32400)
Analog: H'FFFFFFCE to H'0000041A (
−5.0 to 105.0)
150C 3506 PID 1 Cooling Coefficient H'00000001 to H'0000270F (0.01 to 99.99)
150E 3507 PID 1 LBA Detection Time H'00000000 to H'0000270F (0 to 9999)
1520 3510 PID 2 Proportional Band Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.1 to 999.9)
to
152E 3517 PID 2 LBA Detection Time H'00000000 to H'0000270F (0 to 9999)
1540 3520 PID 3 Proportional Band Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.1 to 999.9)
to
154E 3527 PID 3 LBA Detection Time H'00000000 to H'0000270F (0 to 9999)
1560 3530 PID 4 Proportional Band Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.1 to 999.9)
to
156E 3537 PID 4 LBA Detection Time H'00000000 to H'0000270F (0 to 9999)
1580 3540 PID 5 Proportional Band Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.1 to 999.9)
to
158E 3547 PID 5 LBA Detection Time H'00000000 to H'0000270F (0 to 9999)
15A0 3550 PID 6 Proportional Band Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.1 to 999.9)
to
15AE 3557 PID 6 LBA Detection Time H'00000000 to H'0000270F (0 to 9999)
15C0 3560 PID 7 Proportional Band Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.1 to 999.9)
to
15CE 3567 PID 7 LBA Detection Time H'00000000 to H'0000270F (0 to 9999)
15E0 3570 PID 8 Proportional Band Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.1 to 999.9)
to
15EE 3577 PID 8 LBA Detection Time H'00000000 to H'0000270F (0 to 9999)
Address
Parameter name Setting (monitor) value Level
Four-byte
mode
Two-byte
mode
