SECTION 4 SYSWAY (E5@J and E5@X Format) Communications Procedures
4-4
■ SYSWAY Command Lists
• No commands will be accepted and no responses will be returned when a memory error (RAM error)
has occurred or during initialization (until the process value is recognized after power is turned ON).
• When a write operation is performed while there is a memory error (EEPROM error), data will not be
written and the command will end with “normal completion.” Read operations will be executed
normally.
Note 1: The number of EEPROM (non-volatile memory) write operations is limited. Therefore, use RAM
write mode when frequently overwriting data.
Note 2: The process value read range is the same as the input’s display range.
Note 3: Status (last 4 bytes)Note 4. Status (first 2 bytes)
• Overflow: Set 1 when the heater current value is greater than 55.0 A.
• Display hold: Set 1 when the control output ON time is less than 100 ms. The previous heater current
value is held.
Category
Header
code
Data
code
Command R/W
Data
length
Remarks
Selecting Communi-
cations Writing
MB 01 Select communications writing
Write 4B
Write mode selection
(See note 1.)
ME 01 Select backup mode
Write None
MA 01 Select RAM write mode
Save operation/
adjustment set value
MW 01 Save operation/adjustment set value
Writing set values WS 01 Write set point
Write 4B
W% 01 Write alarm value 1
W% 02 Write alarm value 2
WB 01 Write proportional band
WN 01 Write integral time
WV 01 Write derivative time
WI 01 Write temperature input shift values
WW 01 Write heater burnout detection
Read set value and
manipulated variable
monitor
RS 01 Read set point
Read 4B
R% 01 Write alarm value 1
R% 02 Write alarm value 2
RB 01 Read proportional band
RN 01 Write integral time
RV 01 Write derivative time
RI 01 Write temperature input shift values
RW 01 Write heater burnout detection
RO 01 Read MV monitor
Read SP upper and
lower limit values
RL 01 Read SP upper and lower limit values
Read 8B
Read both upper/
lower limit val-
ues at once
Read process value RX 01 Read process value Read 8B See note 2.
Read the heater
current monitor
RZ 01 Heater current value monitor
Read 8B See note 3.
Read the initial status RU 01 Read the initial status Read 5B See note 4.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
000000000000 000
7 6 5 4 3 2 1 0
000000
10
Bit position Bit position
Overflow
Display hold
Control ON/OFF PID
Output operation: Direct Reverse
