Setting the SP Upper and Lower Limit Values Section 4-6
Switching 40% AT
Execute/Cancel
When AT-1 (40% AT Execute/Cancel) is set for either the Event Input Assign-
ment 1 or Event Input Assignment 2 parameter, 40% AT will be executed
when event input 1 or 2 turns ON and will be cancelled when the input turns
OFF.
Switching Setting
Change Enable/
Disable
When WTPT (Setting Change Enable/Disable) is set for either the Event Input
Assignment 1 or Event Input Assignment 2 parameter, the setting change will
be disabled when event input 1 or 2 turns ON and will be enabled when the
input turns OFF.
Switching Alarm
Latch Cancel
When LAT (Alarm Latch Cancel) is set for either the Event Input Assignment 1
or Event Input Assignment 2 parameter, all alarm latches (alarms 1 to 3,
heater burnout, HS alarm, and heater overcurrent latch) will be cancelled
when event input 1 or 2 turns ON.
Parameters
4-6 Setting the SP Upper and Lower Limit Values
4-6-1 Set Point Limiter
The setting range of the set point is limited by the set point limiter. The set
point limiter is used to prevent the control target from reaching abnormal tem-
peratures. The upper- and lower-limit values of the set point limiter are set
using the Set Point Upper Limit and Set Point Lower Limit parameters in the
initial setting level. When the set point limiter is reset, the set point is forcibly
changed to the upper- or lower-limit value of the set point limiter if the set point
is out of the limiter range. Also, when the input type and the temperature unit,
scaling upper-limit value, or lower-limit value are changed, the set point limiter
is forcibly reset to the input setting range or the scaling upper- or lower-limit
value.
Setting Input contact Status
Event input 1 or 2 OFF 40% AT cancelled
Event input 1 or 2 ON 40% AT executed
Setting Input contact Status
Event input 1 or 2 OFF Enabled
Event input 1 or 2 ON Disabled
Setting Input contact Status
Event input 1 or 2 OFF ---
Event input 1 or 2 ON Cancelled
Symbol Parameter: level Description
ev-1 Event Input Assignment 1: Initial setting level Function of
event input func-
tion
ev-2 Event Input Assignment 2: Initial setting level
ev-m Number of Multi-SP Uses: Initial setting level
