Be sure to apply Class D grounding (100Ω or lower grounding resistance) to the ground wire of the
I/O cable.
Do not share the ground wire with some other devices or connect it to the beam of the building. The
product may be adversely affected.
Determine the contact point as near as possible to shorten the ground wire as much as possible.
The product may be adversely affected.
For positive ground, please refer to cautions described in the setup manual.
Do not touch the optical surface of the camera or the lighting section during wiring or installation. It
may affect the characteristics.
Mounting (FH-SMDA-GS050B)
When doing the following, be sure to turn OFF the power of the 3D vision sensor or connected pe-
ripheral devices. Not doing so leads to a product failure.
- Cable connection and wiring
- Connector mounting/removal
Tighten the mounting screws securely using the defined torque. (Screw: M4 x 4, Tightening torque:
1.2 N•m)
Do not apply torsional stress to the cable. Doing so may cause cable breakage.
Secure the minimum bending radius of the cable. If it cannot be secured, the cable may be broken.
Others (FH-SMDA-GS050B)
Use only the dedicated cable (FHV-VNBX / FHV-VNLBX and FHV-VSDX-BX / FHV-VSDX-LBX).
Otherwise, the product may malfunction or be broken.
If anything abnormal occurs, for example, strange smell/sound is detected, the main unit gets very
hot, or a smoke comes, stop using the product, turn OFF the product, and consult OMRON’s branch
or sales office.
Do not disassemble, deform by pressurizing, incinerate, repair, or alter this product.
When disposing of the product, treat as industrial waste.
Do not use the product for atomic power or safety circuits endangering human lives.
Do not drop the product or expose it to abnormal vibration or impact. Doing so may lead to product
failure.
When operating the robot by using the vision sensor measurement results, be sure to check the
measurement result data on the robot side and take fail-safe measures, such as operating the robot
only after confirming that the data is within the robot's range of motion.
3D Vision Sensor measurements are relative, not absolute. It cannot be used as a measurement
sensor.
Camera Calibration Target (FH-XCAL-S)
Install and store the product in a location that meets the following conditions:
Ambient temperature and relative humidity do not exceed the range of specifications
No rapid changes in temperature (place where dew does not form)
No presence of corrosive or flammable gases
Place free of dust, salts and iron particles
Place free of vibration and shock
Precautions for Safe Use
19
FH Series Vision System Hardware Setup Manual for 3D Robot Vision (Z436-E1)
