Precautions for Correct Use

Please observe the following precautions to prevent failure to operate, malfunction, or undesirable ef-

fect.

Installation and Storage Sites (FH-5050)

Install and store the product in a location that meets the following conditions:

• Surrounding temperature of 0 to +45°C (-20 to +65°C in storage)

• No rapid changes in temperature (place where dew does not form)

• Relative humidity of between 35 to 85%

• No presence of corrosive or flammable gases

• Place free of dust, salts and iron particles

• Place free of vibration and shock

• Place out of direct sunlight

• Place where it will not come into contact with water, oils or chemicals

• Place not affected by strong electro-magnetic waves

• Place not near to high-voltage, or high-power equipment

Orientation of Product (FH-5050)

• For efficient heat dissipation, install the product only with the orientation written in this manual or the

Instruction Sheet. Install the product so that the air can flow freely through its cooling vents.

Ambient Temperature (FH-5050)

• To secure good ventilation, install the product with clearance written in this manual or the Instruction

Sheet.

• Do not install the product immediately above significant heat sources, such as heaters, transform-

ers, or large-capacity resistors.

• Use the product within the operating temperature range based on the specifications of it.

• Install a forced cooling fan or air conditioner not to exceed the operating temperature range when

the ambient temperature is close to the upper limit of its range.

Noise Resistance (FH-5050)

• Do not install the Sensor Controller in a cabinet with high-voltage equipment installed.

• Mount the Sensor Controller at 200 [mm] or more from power cables apart.

Component Installation and Handling (FH-5050)

• Touching Signal Lines:

When touching a terminal part or a signal wire in a connector, take anti-static measures using a wrist

strap or another device to prevent damage from static electricity.

• Handling a USB Memory/SD memory card: (Refer to Using External Storage Device in the Vision

System FH/FHV Series User’s Manual (Cat. No. Z365).

Precautions for Correct Use

FH Series Vision System Hardware Setup Manual for 3D Robot Vision (Z436-E1)
