3-5
LCD and Cable
Specification
LCD Monitor
Model FZ-M08
Size 8.4 inches
Type Liquid crystal color TFT
Resolution 1,024 x 768 dots
Input signal Analog RGB video input 1 channel
Supply Voltage 21.6 to 26.4 VDC
Current consumption Approx. 0.7 A max.
Ambient temperature
range
Operating: 0 to +50°C, Storage: -25 to +65°C (with no icing or condensation)
Ambient humidity range Operating and Storage: 35 to 85% (with no condensation)
Weight Approx. 1.2kg
Accessories Instruction Sheet and 4 mounting brackets
LCD Monitor Cable
Model FZ-VM
Vibration (resistance) 10 to 150 Hz, Single amplitude 0.15 mm, 3 directions, 8 strokes, 4 times
Ambient temperature
range
Operation: 0 to +50°C, Storage: -20 to +65°C (with no icing or condensation)
Ambient humidity range Operating and Storage: 35 to 85% (with no condensation)
Ambient atmosphere No corrosive gases
Material Cable sheath: heat-resistant PVC Connector: PVC
Minimum bending radius 75 mm
Weight Approx. 170g
Precautions for Correct Use
Use the DVI-Analog Conversion Cable for Touch Panel Monitor: FH-VMDA when connect the
Sensor Controllers to the LCD monitor: FZ-M08. FZ-VM cable can use by combining the DVI-I -
RGB Conversion Connector: FH-VMRGB.
3 Configuration
3-25
FH Series Vision System Hardware Setup Manual for 3D Robot Vision (Z436-E1)
3-5 LCD and Cable
3
