Connecting the Sensor Controller and Monitor with a Switcher and Split-
ter
• Do not use devices that may require re-recognition of the monitor by the Sensor Controller when a
switching operation was performed. If such re-recognition processing happens at switching opera-
tion, it may cause measurement time to be longer
.
Installation Location (FH-SMDA-GS050B)
In order to prevent the product from becoming inoperable or malfunction, and to prevent other adverse
ef
fects to the performance or equipment, please observe the following.
• A location where the ambient temperature does not exceed the rated range.
• A location where the temperature does not vary sharply (condensation occurs).
• A location where relative temperature does not exceed a range of 35-85%.
• A location not exposed to corrosive gases or combustible gases.
• A location not exposed to dust, salt, or metal powder.
• A location not exposed to direct vibration or impact.
• A location not exposed to strong disturbance light (laser light, arc welding light, or ultraviolet light).
• A location not near a heating appliance or exposed to direct sunlight.
• A location not exposed to mist of water, oil, or chemicals or misty atmosphere.
• A location not exposed to strong magnetic/electric fields.
• A location not near a high-voltage device or power device
Power Supply, Connection, and Wiring (FH-SMDA-GS050B)
• If using a commercially available switching regulator, earth the frame ground terminal.
•
If the power supply line has surge, connect a surge absorber according to the operational environ-
ment to use the product.
• After wiring the cables, confirm if the power supply is appropriate, if there is miswiring such as short-
circuit of load, or if the load current is appropriate. Otherwise, the product may be broken due to
miswiring etc.
• Do not put load on the cables and connectors before wiring them.
• Turn on the power of the 3D Vision Sensor at the same time as or before turning on the power of the
FH sensor controller.
• When turning OFF the power, confirm that data have been saved completely before starting opera-
tions.
- When data are saved by operating the 3D vision sensor, the saving process must have been com-
pleted and the following user operations must be possible.
- When data are saved using communication commands, processing of the applicable commands
must have been completed and the busy state is OFF.
• Attach the cable straight with the terminal correctly aligned. Forcibly attaching the cable may bend
the terminal, resulting in failure or communication error.
• Insulate the unused signal lines of the I/O cable so that the signal lines do not come into contact
with other signal lines.
Maintenance (FH-SMDA-GS050B)
• Turn OFF the power and confirm safety before starting maintenance.
Precautions for Correct Use
23
FH Series Vision System Hardware Setup Manual for 3D Robot Vision (Z436-E1)
