5-5
Camera Installation
Guidelines and precautions for Sensor Controller installation when cameras are also installed.
For handling and function information for specific cameras, refer to the appropriate instruction sheet.
5-5-1
FH-5050
WARNING
If you keep watching the LED light, it may have an adverse effect on the eyes, do not stare
directly into the light emitted from the LED. If a specular object is used, take care not to allow
reflected light to enter your eyes.
Caution
Please take fail-safe measures on your side in preparation for an abnormal signal due to sig-
nal conductor disconnection and/or momentary power interruption. An abnormal operation
may result in a serious accident.
Precautions for Safe Use
• Use specialized cameras and cables for the product. If not, it may cause malfunction or dam-
age.
•
Make sure to turn off the power when attach or detach cameras or cables. Connecting cables
while the power is supplied may cause malfunction or damage to cameras or peripheral devi-
ces.
• Since cables to which bending is frequently applied is easily broken, use the robotic cable
type (bending resistant cable) to prevent damages.
• Do not apply torsion stress to cables. If not, it may cause damage to cables.
• Secure the minimum bending radius of cables. If not, it may cause damage to cables.
• While the power is ON or immediately after the power is turned OFF, the Sensor Controller
and camera case are still hot. Do not touch the case.
• Do not ground the positive terminal of the 24 VDC power supply.
Precautions for Correct Use
Maintenance
•
Turn OFF the power and ensure the safety before maintenance.
• Clean the lens with a lens-cleaning cloth or air brush.
• Lightly wipe off dirt with a soft cloth.
• Dirt on the image element must be removed using an air brush.
• Do not use thinners or benzine.
• When installing / replacing the camera, reset the parameter settings of the corresponding
Camera Image Input processing item.
5 Setup and Wiring
5-10
FH Series Vision System Hardware Setup Manual for 3D Robot Vision (Z436-E1)
