5-4
Setup Touch Panel Monitor or Moni-
tor
Describes the notifications of Sensor Controller when you setup Touch Panel Monitor or Monitor.
For handling or functions of monitor, refer to each of instruction sheet.
5-4-1
FH-5050
Precautions for Safe Use
• Use specialized cameras and cables for the product. If not, it may cause malfunction or dam-
age.
• Make sure to turn off the power when attach or detach cameras or cables. Connecting cables
while the power is supplied may cause malfunction or damage to cameras or peripheral devi-
ces.
• Do not apply torsion stress to cables. If not, it may cause damage to cables.
• Secure the minimum bending radius of cables. If not, it may cause damage to cables.
• DVI-I connector: Please insert the connector perpendicularly so that the connector resin part
and pin are not rubbing against each other. Damaged pin may cause contact failure due to
generation and invasion of resin powder.
• Do not ground the positive terminal of the 24 VDC power supply when connecting the Sensor
Controller and FH-MT12 using a USB cable. The internal circuits may cause a short-circuit
and result in malfunction.
Precautions for Correct Use
When connecting the sensor controller and monitor with a switcher and splitter
Do not use devices that may require re-recognition of the monitor by the Sensor Controller
when a switching operation was performed. If such re-recognition processing happens at
switching operation, it may cause measurement time to be longer.
When fix the DVI connector
If difficult to fix the bilateral screws of DVI connector, once loosen these. Then retry to fix, again.
5 Setup and Wiring
5-9
FH Series Vision System Hardware Setup Manual for 3D Robot Vision (Z436-E1)
5-4 Setup Touch Panel Monitor or Monitor
5
5-4-1 FH-5050
