3-2-2
Camera Cable
Specification
• Camera cable (Ethernet, straight)
Item FHV-VNBX 3M FHV-VNBX 5M FHV-VNBX 10M
Cable length 3 m 5 m 10 m
Cable type Bending resistance cable
Connector type Straight connector
Outer diameter 6.3 + 0.6 mm dia.
Min. bending radius 38 mm
Usage environ-
ment
Ambient temper-
ature range
Operating: -30 to +80°C, Storage: -30 to +100°C (with no icing or conden-
sation)
Ambient humidi-
ty range
Operating & Storage: 0 to 93% (With no condensation)
Ambient atmos-
phere
No corrosive gases
Vibration toler-
ance
Oscillation frequency: 10 to 150Hz, Half amplitude: 0.35 mm, Vibration di-
rection: X/Y/Z, Sweep time: 8 minutes/count, Sweep count: 10 times
Shock resist-
ance
Impact force: 150 m/s
2
, T
est direction: 6 directions, three time each (up/
down, front/behind, left/right)
Material Mold part: Nylon, Thermoplastic polyurethane, Sheath part: Low friction
PVC
Weight Approx. 220 g Approx. 330 g Approx. 590 g
• Camera cable (Ethernet, right angle)
Item FHV-VNLBX 3M FHV-VNLBX 5M FHV-VNLBX 10M
Cable length 3 m 5 m 10 m
Cable type Bending resistance cable
Connector type Right angle connector
Outer diameter 6.3 + 0.6 mm dia.
Min. bending radius 38 mm
Usage environ-
ment
Ambient temper-
ature range
Operating: -30 to +80°C, Storage: -30 to +100°C (with no icing or conden-
sation)
Ambient humidi-
ty range
Operating & Storage: 0 to 93% (With no condensation)
Ambient atmos-
phere
No corrosive gases
Vibration toler-
ance
Oscillation frequency: 10 to 150Hz, Half amplitude: 0.35 mm, Vibration di-
rection: X/Y/Z, Sweep time: 8 minutes/count, Sweep count: 10 times
Shock resist-
ance
Impact force: 150 m/s
2
, T
est direction: 6 directions, three time each (up/
down, front/behind, left/right)
Material Mold part: Nylon, Thermoplastic polyurethane, Sheath part: Low friction
PVC
Weight Approx. 220 g Approx. 330 g Approx. 590 g
3 Configuration
3-13
FH Series Vision System Hardware Setup Manual for 3D Robot Vision (Z436-E1)
